CFMoto Engine Oil Dipstick | w/ Linhai & CFMoto Cross-Reference

Replaces OEM: 0110-013001 / 172MM-013001 | Linhai: 1BE-15363-00

Fits multiple CFMoto 250cc-800cc engines | Includes dipstick and O-ring (18×3.55mm)

Direct replacement for CFMoto part numbers: 0110-013001 / 172MM-013001 / 0GR0-011005

📋 Product Overview

This is an OEM-grade replacement engine oil dipstick for CFMoto engines, directly replacing original part numbers 0110-013001 / 172MM-013001. It fits multiple CFMoto 250cc-800cc engine models and is used to check engine oil level. The kit includes both the dipstick rod and the O-ring seal.

✨ OEM Quality: Manufactured to CFMoto factory specifications, ensuring perfect fitment and accurate oil level readings. Includes cross-reference to Linhai and updated CFMoto part numbers.

📦 Kit Contents & Part Number Cross-Reference

Oil Dipstick Rod CFMoto: 0110-013001 / 172MM-013001 CFMoto (New): 0GR0-011005 Linhai Code: 35224 / 1BE-15363-00

O-Ring Seal (18×3.55mm) CFMoto: 0110-013030 / O-SEAL RING 18x3.55 Linhai Code: 10844 / B920183551 Dimensions: 18mm ID × 3.55mm thickness

📐 Specifications

OEM Replacements0110-013001 / 172MM-013001
0GR0-011005

Linhai Code35224 / 1BE-15363-00

O-Ring Size18×3.55mm

MaterialOil-resistant polymer + rubber O-ring

🔧 Compatible Engine Series

172MM Series172MM / 172MM-A / 172MM-F250cc

1P72MM Series1P72MM-A / A1 / A2250cc

191R / 196S Series191R-X550 / 196S-C550cc / 600cc

2V91W Series2V91W(X8/Z8/S) / CF800ATR-2/CF800UTR800cc

CF188 SeriesCF188 / CF188-A / CF188-C500cc

🔧 Compatible CFMoto Engines (Complete List)

ENGINE 172MM 250cc
ENGINE 172MM-A 250cc
ENGINE 172MM-F 250cc
ENGINE 191R-X550 CForce 550
ENGINE 196S-C Z6 600
ENGINE 1P72MM-A 250cc
ENGINE 1P72MM-A(A1) 250cc
ENGINE 1P72MM-A(A2) 250cc
ENGINE 2V91W FOR CF800ATR-2 CForce 800
ENGINE 2V91W FOR CF800UTR ZForce Z8-EX
ENGINE 2V91W(X8) X8 800
ENGINE 2V91W(Z8) Z8 800
ENGINE 2V91W(Z8-US) Z8 800
ENGINE 2V91W-S CForce 800
ENGINE CF188 500cc
ENGINE CF188-A U5 500
ENGINE CF188-C 500cc

📌 Note: This oil dipstick is suitable for the above CFMoto 250cc-800cc engines, covering 172MM, 1P72MM, 191R-X550, 196S-C, 2V91W, and CF188 series. Also compatible with Linhai engines using the same specification.

⚙️ Features & Benefits

Direct OEM Replacement: Replaces CFMoto original part numbers 0110-013001 / 172MM-013001 / 0GR0-011005
Complete Cross-Reference: Includes Linhai code 35224 (1BE-15363-00) and O-ring cross-reference (10844 / B920183551)
Accurate Readings: Clear measurement markings for precise oil level checks
Complete Kit: Includes both dipstick rod and replacement O-ring (18×3.55mm)
Durable Construction: Made from high-quality oil-resistant materials for long-term reliability
Wide Compatibility: Fits multiple CFMoto 250cc-800cc engines and compatible Linhai models

✅ Essential for Routine Maintenance: The oil dipstick is a critical tool for checking engine oil level. Regular oil level checks ensure proper engine lubrication, preventing damage from low oil conditions. This OEM replacement part provides accurate readings and perfect fitment for your CFMoto or Linhai engine.

🔧 Installation & Usage Guide

Oil Level Check: Engine should be warm, parked on level ground. Remove dipstick, wipe clean, reinsert fully, then remove again to read level.
O-Ring Replacement: Always replace the O-ring (18×3.55mm) when installing a new dipstick to ensure proper sealing and prevent leaks.
Proper Reading: Oil level should be between the minimum and maximum marks. Do not overfill.
Installation: Insert dipstick fully into the tube until seated. Ensure O-ring creates a tight seal.
Maintenance Tip: Inspect O-ring periodically for cracks or hardening; replace as needed to prevent oil seepage.

⚠️ Compatibility Check: Before ordering, verify your engine model is in the compatible list. This is an OEM replacement part, directly replacing CFMoto part numbers 0110-013001 / 172MM-013001 / 0GR0-011005 and Linhai 1BE-15363-00.

📑 Complete Cross-Reference Summary:

Dipstick: CFMoto 0110-013001 / 172MM-013001 / 0GR0-011005 | Linhai 35224 / 1BE-15363-00
O-Ring (18×3.55mm): CFMoto 0110-013030 / O-SEAL RING 18x3.55 | Linhai 10844 / B920183551

This kit includes both components for a complete replacement solution across CFMoto and Linhai platforms.
