Timing Chain Guide

Brand: Mortch Motor
Product Code: MICF0180-023A00

Product Viewed: 5

Availability: In Stock

Weight: 0.22kg

0 reviews / Write a review

US$16.80

Shipping To：

More Quotes

CFMoto Timing Chain Guide & Tensioner Plate

Chain Guide: CF188-023400 / 0180-023400 | 35159 / 1BE-12231-00
Tensioner Plate: CF188-023300 / 0180-023300 | 35160 / 1BE-12241-00

Fits CFMoto 500cc / 600cc / 625cc Multiple Models (CF188 & 196S Series Engines)

📋 Overview

These timing chain guide and tensioner plate are genuine quality replacement parts for CFMoto vehicles. They guide the timing chain and provide the contact surface for the tensioner, ensuring smooth chain operation and accurate valve timing. Directly replace OEM part numbers CF188-023400 / 0180-023400 (chain guide) and CF188-023300 / 0180-023300 (tensioner plate), and are compatible with Linhai part numbers 35159 / 1BE-12231-00 (chain guide) and 35160 / 1BE-12241-00 (tensioner plate).

Fits CFMoto 500cc, 600cc and 625cc ATV, UTV and SSV models equipped with CF188, 196S-B, and 196S-C engines.

✨ OEM Quality: Made from wear-resistant materials with specially treated surfaces, ensuring smooth operation and reduced chain wear over long service life.

📐 Part Number Cross Reference

Timing Chain Guide

CFMoto:

CF188-023400 / 0180-023400

Linhai:

35159 / 1BE-12231-00

Tensioner Plate

CFMoto:

CF188-023300 / 0180-023300

Linhai:

35160 / 1BE-12241-00

🔧 Compatible Models & Engines

🏍️ 500cc Series (CF188/CF188-A/CF188-B Engine) - X5, UForce 500

ATV CF500 X5 CF188
ATV CF500-2 X5 CF188
ATV CF500-2A X5 CF188
ATV CF500-5 X5 CF188
ATV CF500-5A X5 CF188
ATV CF500-5B X5 CF188-B
ATV CF500-5C X5 CF188-B
ATV CF500-A X5 CF188
ATV CF500-B X5 CF188
ATV CF500-C X5 CF188
ATV CF500-D X5 CF188
ATV CF500-E X5 CF188
UTV CF500-3 UForce 500 U5 CF188-A

🏍️ 600/625cc Series (196S-B/196S-C Engine) - X6, UForce U6, Z6

ATV CF600-B X6 196S-B(X6)
ATV CF600-C X6 196S-B(X6)
ATV CF625-2 X6 196S-B(X6)
ATV CF625-2A X6 196S-B(X6)
ATV CF625-B X6 196S-B(X6)
ATV CF625-C X6 196S-B(X6)
UTV CF600-5 UForce U6 196S-B(U6)
SSV CF600-3 Z6 196S-C
SSV CF600-6 Z6 196S-C
SSV CF625-3 Z6 196S-C
SSV CF625-6 Z6 196S-C

📌 Compatibility Note: These timing chain guide and tensioner plate fit the CFMoto models listed above, covering CF188, CF188-A, CF188-B, 196S-B and 196S-C engines, including X5, X6, UForce 500 (U5), UForce 600 (U6), Z6 series and more.

⚙️ Features

Direct OEM Replacement: Perfectly matches CFMoto OEM part numbers, also compatible with Linhai part numbers, ensuring precise fitment.
Wear-Resistant Material: Made from high-strength wear-resistant material with smooth surface, reducing chain friction and wear.
Precise Guidance: Ensures timing chain runs in the correct path, preventing chain slap and misalignment.
Noise Reduction: Effectively reduces timing chain operating noise.
Extended Chain Life: Reduces direct contact between chain and metal components, prolonging timing chain service life.

✅ Importance of Timing Chain Guide Replacement: Timing chain guides are subjected to constant chain friction and pressure, causing surface wear over time. Worn guides can cause unstable chain operation, noise, and even chain skipping, leading to incorrect valve timing and potential engine damage. When servicing the timing system, inspect the guides and tensioner plate for wear and replace if necessary.

⚠️ Verify Before Ordering: Please confirm your engine model is in the compatibility list. These are timing chain guide and tensioner plate components. It is recommended to replace the timing chain and tensioner simultaneously for best results.
