Fuel Pump

Brand: Mortch Motor
Product Code: MICF901F-150900-10000

Product Viewed: 3

Availability: 21

Weight: 0.81kg

0 reviews / Write a review

US$71.01

Shipping To：

More Quotes

Qty

Buy Now

Tell a Friend Ask a Question

CF Moto Fuel Pump Assembly

New Part Number: 901F-150900-10000

Old Part Number: 901F-15.09.00 (Superseded)

Specification: Total Length approx. 20cm

Product Type: Fuel System | Fuel Pump

Function: Supplies fuel to the engine under a certain pressure and flow

OEM specification fuel pump assembly, including fuel pump, plastic support, preliminary filter, fine filter and pressure regulator. New part number 901F-150900-10000 is the factory upgrade model, fully replacing old part number 901F-15.09.00.

? Product Overview

This product is an OEM-quality fuel pump assembly for CF Moto vehicles, with new part number 901F-150900-10000, fully superseding the old part number 901F-15.09.00. The fuel pump assembly is a core component of the vehicle's fuel system, responsible for supplying fuel to the engine at a specific pressure and flow rate.

The fuel pump assembly is located inside the fuel tank and includes the fuel pump, plastic support, preliminary filter, fine filter, and pressure regulator. Manufactured with high-quality materials, ensuring reliable fuel delivery and long service life. Produced strictly according to CF Moto original technical standards, ensuring precise fit and reliable performance.

? OEM Quality Assurance: Manufactured strictly according to CF Moto original technical standards. Material, dimensional accuracy, and performance parameters are identical to original parts, ensuring perfect fit and reliable fuel delivery.

? Specifications & Important Notes

● Location: The fuel pump is located in the fuel tank.
● Do not operate dry: Do not operate the fuel pump in dry condition to prevent damage.
● Handle with care: Always handle the fuel pump gently.
● Total Length: Approx. 20cm

⚠️ Never drop the fuel pump: Never drop the fuel pump, especially on a hard surface. Such a shock to the pump can cause damage.

⚡ Fuel Pump Wiring: Battery supplies power for fuel pump assembly via fuel pump relay, which connects the fuel pump circuit only with engine started.

? Fuel Pressure Test

Connect the fuel pressure gauge to the fuel outlet and tighten the joint with a clamp to prevent fuel leaks.
Route according to the correct circuit.
Turn both ignition switch and engine stop switch on.
At this moment, the fuel pump will operate for 5 seconds. After the fuel pump stops running, fuel pressure should be in specification; otherwise, replace the fuel pump.

✅ Pressure Specification: After the fuel pump stops running, the holding pressure should be 0.25MPa for at least 5 minutes; otherwise, replace the fuel pump.

? Applicable Models List

This fuel pump assembly (901F-150900-10000 / 901F-15.09.00) fits the following CF Moto models:

?️ 600/625cc Series

ATV CF600ATR-2L(T3b) CForce 625 Touring
ATV CF600ATR-2S(T3b) CForce 625
ATV CF600ATR-L(T3a) CForce 600
ATV CF600ATR-L(T3b) CForce 600
ATV CF600AU-3L CForce 600 Touring/625 Touring
ATV CF600AU-3S CForce 600/625
ATV CF600AU-L(EU168) CForce 600
ATV CF600AU-L(INTERNATIONAL) CForce 600
ATV CF600AU-L CForce 600 EPS
ATV CF600AZ-3L CForce 600
ATV CF600AZ-3S CForce 600
ATV CF600-B X6
ATV CF600-C X6
ATV CF625-2 X6
ATV CF625-2A X6
ATV CF625-B X6
ATV CF625-C X6

?️ 500cc Series

ATV CF500-5B X5
ATV CF500-5C X5
ATV CF500ATR CForce 520
ATV CF500ATR-11L GOES TERROX 500L
ATV CF500ATR-11S GOES TERROX 500S
ATV CF500ATR-2L(T3a) CForce 520L
ATV CF500ATR-2L(T3b) CForce 520L
ATV CF500ATR-2S(T3a) CForce 520S
ATV CF500ATR-2S(T3b) CForce 520S
ATV CF500ATR-3 CForce 520
ATV CF500ATR-3(T3a) CForce 520
ATV CF500ATR-5L(T3b) COBALT MAX T3
ATV CF500ATR-5S(T3b) COBALT T3
ATV CF500ATR-A CForce 550
ATV CF500AU-6B CForce 550
ATV CF500AU-6L CForce 550
ATV CF500AU-7A CForce 520S
ATV CF500AU-7C CForce 520L
ATV CF500AU-7L CForce 520L
ATV CF500AU-7LA GOES TERROX 500L
ATV CF500AU-7LF CForce 520L
ATV CF500AU-7S CForce 520 S
ATV CF500AU-7SA GOES TERROX 500S
ATV CF500AU-7SF CForce 500S/CForce 520S
ATV CF500AU-8L COBALT MAX L7e
ATV CF500AU-8S COBALT L7e
ATV CF500-E X5

?️ 400cc Series

ATV CF400ATR CForce 450
ATV CF400ATR-2L(T3a) CForce 450L
ATV CF400ATR-2L(T3b) CForce 450L
ATV CF400ATR-2S(T3a) CForce 450S
ATV CF400ATR-2S(T3b) CForce 450S
ATV CF400ATR-4L GOES TERROX 400L
ATV CF400ATR-4S GOES TERROX 400S
ATV CF400ATR-5L(T3b) IRON MAX T3
ATV CF400ATR-5S(T3b) IRON T3
ATV CF400ATR-L CForce 450L
ATV CF400AU CForce 400S/450S
ATV CF400AU-2L IRON MAX L7e
ATV CF400AU-2S IRON L7e
ATV CF400AU-A CForce 450S
ATV CF400AU-B CForce 450L
ATV CF400AU-G GOES TERROX 400S
ATV CF400AU-L CForce 400L/450L
ATV CF400AU-LA GOES TERROX 400L

? Application Note: This fuel pump assembly (901F-150900-10000 / 901F-15.09.00) fits the CF Moto 400cc, 500cc, and 600cc series ATV models listed above. New part number 901F-150900-10000 fully replaces old part number 901F-15.09.00. If your specific model is not listed, please contact our customer service with your Vehicle Identification Number (VIN) for confirmation.

✅ Signs of Failure: Fuel pump failure may manifest as:
• Difficulty starting the engine.
• Poor acceleration or hesitation.
• Engine stalling while driving.
• Excessive noise from the fuel pump during operation.
• Insufficient fuel pressure.
If you encounter these issues, inspect and replace the fuel pump assembly promptly.

✅ Installation Tips: Before installation, ensure the fuel tank is clean to prevent contaminants from entering the fuel system. It is recommended to replace the fuel filter at the same time as the fuel pump. After installing the new fuel pump, check that all hose connections are secure and leak-free. Before starting the engine for the first time, turn the ignition switch on and off several times (without starting the engine) to allow the fuel system to build pressure.

⚠️ Important Notice: This product is a CF Moto fuel pump assembly, new part number 901F-150900-10000, fully replacing old part number 901F-15.09.00, total length approx. 20cm. It is applicable for the CF Moto 400cc, 500cc, and 600cc series ATV models listed above. Minor variations may exist between different model years or production batches. If your specific model is not listed, please contact our customer service with your Vehicle Identification Number (VIN) to verify compatibility. Images are for reference only; the actual product may differ slightly due to batch variations.

🔧 Compatibility Notice

Please verify that this part fits your specific vehicle model and year. Many vehicles share similar names but use different components depending on year or market region.
We strongly recommend cross-checking with your vehicle's owner's manual or contacting us for confirmation before placing your order.

📄 Product Disclaimer

Product images, measurements, and descriptions are for reference only. Slight variations in color or appearance may occur due to manufacturing batches or photography lighting—functional specifications remain identical to the ordered part.
Professional installation is mandatory. Mortch Motor assumes no liability for damages, injuries, or losses resulting from improper installation, misuse, unauthorized modification, or abnormal operation.

💰 Import Duties & Taxes

All listed prices EXCLUDE shipping costs, import duties, taxes, and customs clearance fees. These charges (if applicable) are determined and collected by your local customs authority and are solely the buyer's responsibility.
In case of return due to unpaid duties/taxes or refusal to clear customs, the buyer shall bear the original shipping cost, return shipping fees, and any associated administrative charges deducted from the refund.

📌 Order Confirmation: By completing your purchase, you acknowledge that you have read, understood, and agreed to all terms above. For any questions, please contact our support team prior to ordering.
