Cylinder Bolts

Brand: Mortch Motor
Product Code: MICF0180-6002E

Product Viewed: 5

Availability: In Stock

Weight: 0.47kg

0 reviews / Write a review

US$12.20

Shipping To：

More Quotes

CFMoto Cylinder Bolt Kit M10×1.25

Left Bolts: CF188-022012 / 0180-022012-0010 (2 pcs)
Right Bolts: CF188-022013 / 0180-022013-0010 (2 pcs)
Washers: CF188-022014 / 0180-022014 (4 pcs)

Specs: M10 × 1.25mm (Diameter × Pitch)
Length: Left Bolts 190mm / Right Bolts 200mm

Fits CFMoto 500cc / 600cc / 625cc Multiple Models (CF188 & 196S Series Engines)

📋 Overview

This cylinder bolt kit is a genuine quality replacement part set for CFMoto vehicles. It secures the cylinder head to the cylinder block, ensuring combustion chamber sealing. The kit includes 4 cylinder bolts and 4 washers, directly replacing OEM part numbers CF188-022012 / 0180-022012-0010 (left bolts, 2 pcs), CF188-022013 / 0180-022013-0010 (right bolts, 2 pcs), and CF188-022014 / 0180-022014 (washers, 4 pcs).

Bolts are M10 × 1.25mm, with left bolts length 190mm and right bolts length 200mm. Fits CFMoto 500cc, 600cc and 625cc ATV, UTV and SSV models equipped with CF188, 196S-B, and 196S-C engines.

✨ OEM Quality: Made from high-strength alloy steel with precision threads, strength grade meets OEM requirements, ensuring uniform and reliable cylinder head clamping force.

📐 Specifications

Left Cylinder Bolts (2 pcs)

Part Number:

CF188-022012 / 0180-022012-0010

Thread Size:

M10 × 1.25mm

Length:

190mm

Right Cylinder Bolts (2 pcs)

Part Number:

CF188-022013 / 0180-022013-0010

Thread Size:

M10 × 1.25mm

Length:

200mm

Cylinder Bolt Washers (4 pcs)

Part Number:

CF188-022014 / 0180-022014

🔧 Compatible Models & Engines

🏍️ 500cc Series (CF188/CF188-A/CF188-B Engine) - X5, UForce 500

ATV CF500 X5 CF188
ATV CF500-2 X5 CF188
ATV CF500-2A X5 CF188
ATV CF500-5 X5 CF188
ATV CF500-5A X5 CF188
ATV CF500-5B X5 CF188-B
ATV CF500-5C X5 CF188-B
ATV CF500-A X5 CF188
ATV CF500-B X5 CF188
ATV CF500-C X5 CF188
ATV CF500-D X5 CF188
ATV CF500-E X5 CF188
UTV CF500-3 UForce 500 U5 CF188-A

🏍️ 600/625cc Series (196S-B/196S-C Engine) - X6, UForce U6, Z6

ATV CF600-B X6 196S-B(X6)
ATV CF600-C X6 196S-B(X6)
ATV CF625-2 X6 196S-B(X6)
ATV CF625-2A X6 196S-B(X6)
ATV CF625-B X6 196S-B(X6)
ATV CF625-C X6 196S-B(X6)
UTV CF600-5 UForce U6 196S-B(U6)
SSV CF600-3 Z6 196S-C
SSV CF600-6 Z6 196S-C
SSV CF625-3 Z6 196S-C
SSV CF625-6 Z6 196S-C

📌 Compatibility Note: This cylinder bolt kit fits the CFMoto models listed above, covering CF188, CF188-A, CF188-B, 196S-B and 196S-C engines, including X5, X6, UForce 500 (U5), UForce 600 (U6), Z6 series and more.

⚙️ Features

Direct OEM Replacement: Perfectly matches CFMoto OEM part numbers, ensuring precise fitment.
High Strength Material: Made from high-strength alloy steel, strength grade meets OEM requirements to withstand cylinder head clamping forces.
Precision Threads: High thread accuracy ensures correct torque application and uniform clamping force distribution.
Left/Right Specific: Left and right bolts have different lengths, strictly following OEM design for correct installation.
Matching Washers: Includes dedicated washers to prevent loosening and distribute clamping force evenly.

✅ Importance of Cylinder Bolt Replacement: Cylinder bolts are among the most critical fasteners in an engine, withstanding significant thermal and mechanical stress. Over time, bolts can fatigue, stretch, or even break. When removing the cylinder head for service or replacing the head gasket, it is recommended to install new cylinder bolts to ensure proper clamping force and reliable sealing. Reusing old bolts may result in insufficient clamping force, leading to head gasket failure and engine damage.

⚠️ Important Note: This kit includes 2 left bolts, 2 right bolts, and 4 washers. Follow the torque sequence and specifications in the service manual during installation. Never reuse old cylinder bolts.
