Radiator Fan

Brand: Mortch Motor
Product Code: MICF9010-180200-3000

Product Viewed: 1

Availability: 9

Weight: 1.18kg

Packing Size: 27.00 x 27.00 x 8.00cm

0 reviews / Write a review

US$52.68

Shipping To：

More Quotes

Qty

Buy Now

Tell a Friend Ask a Question

CF Moto Radiator Fan

Part Number: 9010-180200-3000

Mounting Hole Distance: 140mm / 208mm (Edge) | 250mm / 253mm (Diagonal)

Product Type: Cooling System | Radiator Fan

Function: Forces air through radiator, enhances cooling efficiency

Product Description: OEM specification radiator fan for forcing air through the radiator at low speeds or idle to enhance cooling efficiency and prevent engine overheating. Suitable for multiple CF Moto ATV and UTV models, covering 400cc-625cc displacement.

📋 Product Overview

This product is an OEM specification radiator fan for CF Moto vehicles, part number 9010-180200-3000. This fan is mounted behind the radiator and automatically activates when coolant temperature reaches a set value during low-speed driving or idling, forcing air through the radiator core to enhance heat dissipation and maintain engine operating temperature within the normal range. Manufactured with high-quality motor and fan blades, it ensures high airflow, low noise, and long service life. Mounting hole distances: 140mm/208mm (edge to edge), 250mm/253mm (diagonal). Suitable for multiple CF Moto ATV and UTV models covering 400cc-625cc displacement, including CForce, GOES TERROX, IRON, COBALT, X5, X6 series, and UForce, it is an ideal choice for cooling system repair and replacement.

Key Information:

Part Number: 9010-180200-3000
Product Name: Radiator Fan
Mounting Hole Distance: Edge: 140mm / 208mm | Diagonal: 250mm / 253mm
Function: Forces air through radiator, enhances cooling efficiency
System: Cooling System
Applicable Displacement: 400cc - 625cc

🔧 OEM Quality Assurance: Manufactured strictly according to CFMoto original technical standards, with motor performance, airflow, and noise control identical to the original part, ensuring proper cooling effect.

📐 Specifications

Part Number:

9010-180200-3000

Product Name:

Radiator Fan

Mounting Hole Distance:

Edge: 140/208mm | Diagonal: 250/253mm

System:

Cooling System

🔧 Complete Fitment List

🏍️ ATV Models

600cc/625cc Series

ATV CF600ATR-L(T3a) CForce 600
ATV CF600ATR-L(T3b) CForce 600
ATV CF600ATR-L(T3b)(GD) CForce 600
ATV CF600AU-L(EU168) CForce 600
ATV CF600AU-L(INTERNATIONAL) CForce 600
ATV CF600-B X6
ATV CF600-C X6
ATV CF625-2 X6
ATV CF625-2A X6
ATV CF625-B X6
ATV CF625-C X6

500cc/520cc/550cc Series

ATV CF500 X5
ATV CF500-2 X5
ATV CF500-2A X5
ATV CF500-5 X5
ATV CF500-5A X5
ATV CF500-5B X5
ATV CF500-5C X5
ATV CF500-A X5
ATV CF500ATR CForce 520
ATV CF500ATR-11L GOES TERROX 500L
ATV CF500ATR-11L(SS) GOES TERROX 500L
ATV CF500ATR-11S GOES TERROX 500S
ATV CF500ATR-2L(T3a) CForce 520L
ATV CF500ATR-2L(T3a)(SS) CForce 520L
ATV CF500ATR-2L(T3b) CForce 520L
ATV CF500ATR-2L(T3b)(GD) CForce 520L
ATV CF500ATR-2L(T3b)(HLG) CForce 520L
ATV CF500ATR-2L(T3b)(SS) CForce 520L
ATV CF500ATR-2S(T3a) CForce 520S
ATV CF500ATR-2S(T3a)(SS) CForce 520S
ATV CF500ATR-2S(T3b) CForce 520S
ATV CF500ATR-2S(T3b)(GD) CForce 520S
ATV CF500ATR-2S(T3b)(SS) CForce 520S
ATV CF500ATR-3 CForce 520
ATV CF500ATR-3(T3a) CForce 520
ATV CF500ATR-5L(T3b) COBALT MAX T3
ATV CF500ATR-5S(T3b) COBALT T3
ATV CF500ATR-A CForce 550
ATV CF500AU-6B CForce 550
ATV CF500AU-6L CForce 550
ATV CF500AU-6L(CA) CForce 550HO
ATV CF500AU-7A CForce 520S
ATV CF500AU-7C CForce 520L
ATV CF500AU-7C(HLG) CForce 520L
ATV CF500AU-7L CForce 520L
ATV CF500AU-7LA GOES TERROX 500L
ATV CF500AU-7LF CForce 520L
ATV CF500AU-7LF(HLG) CForce 520L
ATV CF500AU-7S CForce 520 S
ATV CF500AU-7S(AU) CForce 520 S
ATV CF500AU-7S(CA) CForce 520 S
ATV CF500AU-7S(US) CForce 500S
ATV CF500AU-7SA GOES TERROX 500S
ATV CF500AU-7SF CForce 500S/CForce 520S
ATV CF500AU-7SF(GD) CForce 500S/CForce 520S
ATV CF500AU-8L COBALT MAX L7e
ATV CF500AU-8S COBALT L7e
ATV CF500-D X5
ATV CF500-E X5
ATV GOES500
ATV GOES500-A

400cc/450cc Series

ATV CF400ATR CForce 450
ATV CF400ATR-2L(T3a) CForce 450L
ATV CF400ATR-2L(T3a)(SS) CForce 450L
ATV CF400ATR-2L(T3b) CForce 450L
ATV CF400ATR-2L(T3b)(HLG) CForce 450L
ATV CF400ATR-2L(T3b)(SS) CForce 450L
ATV CF400ATR-2S(T3a) CForce 450S
ATV CF400ATR-2S(T3a)(HLG) CForce 450S
ATV CF400ATR-2S(T3a)(SS) CForce 450S
ATV CF400ATR-2S(T3b) CForce 450S
ATV CF400ATR-2S(T3b)(GD) CForce 450S
ATV CF400ATR-2S(T3b)(HLG) CForce 450S
ATV CF400ATR-2S(T3b)(SS) CForce 450S
ATV CF400ATR-4L GOES TERROX 400L
ATV CF400ATR-4L(SS) GOES TERROX 400L
ATV CF400ATR-4S GOES TERROX 400S
ATV CF400ATR-5L(T3b) IRON MAX T3
ATV CF400ATR-5S(T3b) IRON T3
ATV CF400ATR-L CForce 450L
ATV CF400AU CForce 400S/450S
ATV CF400AU(AU) CForce 400S
ATV CF400AU(CA) CForce 400S
ATV CF400AU(US) CForce 400S
ATV CF400AU-2L IRON MAX L7e
ATV CF400AU-2S IRON L7e
ATV CF400AU-A CForce 450S
ATV CF400AU-A(HLG) CForce 450S
ATV CF400AU-B CForce 450L
ATV CF400AU-B(HLG) CForce 450L
ATV CF400AU-G GOES TERROX 400S
ATV CF400AU-L CForce 400L/450L
ATV CF400AU-L(CA) CForce 400L/450L
ATV CF400AU-L(RU) CForce 400L/450L
ATV CF400AU-LA GOES TERROX 400L
ATV CF400AU-LF CForce 450L
ATV CF400AU-SF CForce 450S
ATV CF400AU-SF(GD) CForce 450S
ATV CF400AU-SF(HLG) CForce 450S

🚜 UTV Models

UTV CF500-3 UForce 500 U5
UTV CF600-5 UForce U6

📌 Fitment Note: This radiator fan (Part # 9010-180200-3000, mounting hole distances edge: 140mm/208mm, diagonal: 250mm/253mm) fits all CF Moto ATV and UTV models listed above. Please verify your specific model is included in the list or measure your original fan mounting hole distances for confirmation. If you have any questions, please contact our customer service with your Vehicle Identification Number (VIN) for compatibility confirmation.

⚠️ Radiator Fan Failure Signs & Installation Tips

Signs that radiator fan needs replacement:

Engine overheating, especially at idle or low speeds
Fan does not spin or spins at abnormal speed
Excessive noise when fan operates
Fan blades damaged or deformed
Fan motor failure

Installation Tips:

Inspect new fan for shipping damage before installation
Verify mounting hole distances match your vehicle
Check fan electrical connector condition
Test fan operation after installation
Check clearance between fan and radiator

📌 Important Notice: This product is a CF Moto OEM specification radiator fan, part number 9010-180200-3000, mounting hole distances edge: 140mm/208mm, diagonal: 250mm/253mm. It fits numerous CF Moto ATV and UTV models listed above. Please verify mounting hole distances match before purchasing. Proper cooling system operation is critical for engine health; professional installation by a qualified technician is recommended. Images are for reference only; the actual product may vary.

🔧 Compatibility Notice

Please verify that this part fits your specific vehicle model and year. Many vehicles share similar names but use different components depending on year or market region.
We strongly recommend cross-checking with your vehicle's owner's manual or contacting us for confirmation before placing your order.

📄 Product Disclaimer

Product images, measurements, and descriptions are for reference only. Slight variations in color or appearance may occur due to manufacturing batches or photography lighting—functional specifications remain identical to the ordered part.
Professional installation is mandatory. Mortch Motor assumes no liability for damages, injuries, or losses resulting from improper installation, misuse, unauthorized modification, or abnormal operation.

💰 Import Duties & Taxes

All listed prices EXCLUDE shipping costs, import duties, taxes, and customs clearance fees. These charges (if applicable) are determined and collected by your local customs authority and are solely the buyer's responsibility.
In case of return due to unpaid duties/taxes or refusal to clear customs, the buyer shall bear the original shipping cost, return shipping fees, and any associated administrative charges deducted from the refund.

📌 Order Confirmation: By completing your purchase, you acknowledge that you have read, understood, and agreed to all terms above. For any questions, please contact our support team prior to ordering.
