CF196S Cylinder Assy

Brand: Mortch Motor
Product Code: MICF0600-6003

Product Viewed: 3

Availability: In Stock

Weight: 3.61kg

0 reviews / Write a review

US$89.69

Shipping To：

More Quotes

CF Moto Cylinder Assembly 594cm³

For 4-Stroke Liquid Cooled CF Moto CF600 CF196 Engine

Includes: Cylinder, Piston, Piston Rings, Piston Pin, Piston Pin Clips

Fits CF Moto 600cc / 625cc X6, U6, Z6 Series Models

📋 Product Overview

This cylinder assembly is a high-quality OEM repair kit for CF Moto CF600 CF196 4-stroke liquid-cooled engines. The cylinder body is marked with 594cm³, representing the single cylinder displacement. The assembly includes the cylinder, piston, piston rings, piston pin, and piston pin clips, providing a complete piston-cylinder component set for engine overhaul. Directly replaces OEM part numbers: Cylinder 196S-023100 / 0600-023100, Piston 196S-040004 / 0600-040004, Piston Rings 196S-0400A0 / 0600-0400A0, Piston Pin CF188-040002 / 0180-040002, Piston Pin Clips CF188-040003 / 0180-040003-0050.

This cylinder assembly is made from high-quality alloy cast iron with precision-honed cylinder bore, ensuring perfect fit with the piston and excellent sealing. Fits CF Moto 600cc/625cc engines equipped with 196S series in X6, U6, and Z6 models.

Specifications:

Parameter	Value
Bore Diameter	96mm
Displacement	600cc
Cylinder Skirt Outer Diameter	103.5mm
Cylinder Middle Height	100mm
Cylinder Total Height	139.5mm
Marked Displacement	594cm³

✨ OEM Quality: Cylinder made from high-quality alloy cast iron with precision honing; piston made from high-strength aluminum alloy with precision machining; piston rings made from quality alloy cast iron for excellent sealing and wear resistance; piston pin and clips heat-treated for reliable strength.

📦 Set Includes

Part Number	Description
196S-023100 / 0600-023100	Cylinder (Marked 594cm³)
196S-040004 / 0600-040004	Piston
196S-0400A0 / 0600-0400A0	Piston Rings
CF188-040002 / 0180-040002	Piston Pin
CF188-040003 / 0180-040003-0050	Piston Pin Clips

🔧 Compatible Models

🏍️ X6 Series (196S-B/X6 Engine)

ATV CF600-B X6 196S-B(X6)
ATV CF600-C X6 196S-B(X6)
ATV CF625-2 X6 196S-B(X6)
ATV CF625-2A X6 196S-B(X6)
ATV CF625-B X6 196S-B(X6)
ATV CF625-C X6 196S-B(X6)

🏍️ U6 Series (196S-B/U6 Engine)

UTV CF600-5 UForce U6 196S-B(U6)

🏍️ Z6 Series (196S-C Engine)

SSV CF600-3 Z6 196S-C
SSV CF600-6 Z6 196S-C
SSV CF625-3 Z6 196S-C
SSV CF625-6 Z6 196S-C

📌 Compatibility Note: This cylinder assembly fits all CF Moto X6, U6, and Z6 series models listed above, equipped with 196S series 600cc/625cc engines. The cylinder is marked with 594cm³ as original identification.

⚙️ Features

Complete Kit: Includes cylinder, piston, piston rings, piston pin, and clips needed for engine overhaul - one purchase completes piston-cylinder component replacement.
Quality Alloy Cast Iron Cylinder: Cylinder made from high-quality alloy cast iron with excellent wear resistance and good heat dissipation.
Precision Honed Bore: Cylinder bore precision-honed for smooth surface finish and optimal sealing with piston rings.
High-Strength Aluminum Alloy Piston: Piston made from high-strength aluminum alloy, lightweight with high strength.
Quality Piston Rings: Piston rings made from quality alloy cast iron for excellent sealing and oil control.

✅ Importance of Cylinder Assembly: The cylinder-piston assembly is the core component of the engine,承受ing repeated exposure to high-temperature, high-pressure combustion gases. After prolonged use, cylinder wear and piston ring wear can cause reduced compression, increased oil consumption, power loss, and starting difficulties. During engine overhaul, replacing the cylinder assembly is the best choice to restore engine performance.

⚠️ Installation Note: Thoroughly clean the crankcase before installation. Use proper tools to install piston rings and piston, avoiding cylinder wall scratches. Ensure piston pin clips are fully seated in their grooves. Use new cylinder head gasket and piston rings, and tighten cylinder head bolts to specified torque.

🔧 Compatibility Notice

Please verify that this part fits your specific vehicle model and year. Many vehicles share similar names but use different components depending on year or market region.
We strongly recommend cross-checking with your vehicle's owner's manual or contacting us for confirmation before placing your order.

📄 Product Disclaimer

Product images, measurements, and descriptions are for reference only. Slight variations in color or appearance may occur due to manufacturing batches or photography lighting—functional specifications remain identical to the ordered part.
Professional installation is mandatory. Mortch Motor assumes no liability for damages, injuries, or losses resulting from improper installation, misuse, unauthorized modification, or abnormal operation.

💰 Import Duties & Taxes

All listed prices EXCLUDE shipping costs, import duties, taxes, and customs clearance fees. These charges (if applicable) are determined and collected by your local customs authority and are solely the buyer's responsibility.
In case of return due to unpaid duties/taxes or refusal to clear customs, the buyer shall bear the original shipping cost, return shipping fees, and any associated administrative charges deducted from the refund.

📌 Order Confirmation: By completing your purchase, you acknowledge that you have read, understood, and agreed to all terms above. For any questions, please contact our support team prior to ordering.
