CFMoto Speed Sensor (RPM Sensor)

OEM Part Number 7020-150400

Fits CFMoto 500cc / 800cc / 1000cc Multiple Models

Product Image

📋 Product Overview

This is a genuine quality speed sensor (RPM sensor) for CFMoto, directly replacing OEM part number 7020-150400. This sensor is used to detect the rotating speed of the engine output shaft and provide the signal for the ECU to determine the vehicle speed. It is a Hall effect sensor that varies its output voltage in response to a magnetic field.

✨ Operating Principle: Hall effect sensors generate pulse signals by sensing changes in the magnetic field from magnets or gears on rotating components. The ECU calculates rotational speed and vehicle speed based on pulse frequency. Advantages include fast response, long service life, and strong anti-interference capability.

📐 Specifications

Part Number: 7020-150400

Type: Hall Effect Sensor

Function: Engine Speed / Vehicle Speed Detection

🔧 Compatible Models

🏍️ 1000cc Series — 2V91Y Engine

CForce 1000 ATV Models:

ATV CF1000ATR CForce 1000 2V91Y-X10
ATV CF1000AU CForce 1000 EPS Overland 2V91Y-X10
ATV CF1000AU-F CForce 1000 2V91Y-C
ATV CF1000AZ CForce 1000 Overland 2V91Y-C
POLICE MOTORCYCLE CF1000AU Government CForce 1000 EPS Overland 2V91Y-X10

ZForce 1000 SSV Models:

SSV CF1000US-2 ZForce 1000 2V91Y-Z1000
SSV CF1000UTR-2 ZForce 1000 2V91Y-Z1000

🏍️ 800/850cc Series — 2V91W Engine

CForce 800/850 ATV Models:

ATV CF800-2 X8 2V91W(X8)
ATV CF800ATR CForce 800 2V91W(X8)
ATV CF800ATR-3 CForce 850XC 2V91W-A
ATV CF800AU-2A CForce 850XC 2V91W-A
ATV CF800AU-2AF CForce 800XC/CForce 850XC 2V91W-D
ATV CF800AZ-2A CForce 800XC 2V91W-A
POLICE MOTORCYCLE CF800AU-2A(Government) CForce 850XC 2V91W-A

ZForce 800 SSV Models:

SSV CF800 ZForce 800EX 2V91W(Z8)
SSV CF800US-A ZForce 800 Trail 2V91W(Z8)
SSV CF800UTR ZForce Z8-EX 2V91W FOR CF800UTR
POLICE MOTORCYCLE CF800(Z8) ZForce 800EX 2V91W(Z8)

UForce 800 UTV Models:

UTV CF800-3 UForce 800 2V91W(U8)
UTV CF800UTR-2 UForce 800 2V91W FOR CF800UTR-2
UTV CF800UU-A UForce 800 2V91W(U8)

🏍️ 500/550cc Series — 191R-Z550 Engine

ZForce 500/550 SSV Models:

SSV CF500US ZForce 500 Trail 191R-Z550
SSV CF500US-EX ZForce 550EX 191R-Z550

📌 Compatibility Note: This speed sensor fits the CFMoto 500cc, 800cc and 1000cc models listed above, including ATV, SSV, UTV and police motorcycle versions. Please verify your original part number is 7020-150400 to ensure correct fitment.

⚙️ Features

Direct OEM Replacement: Exactly matches CFMoto part number 7020-150400.
Hall Effect Technology: Non-contact detection using Hall effect principle, fast response, long service life.
Precise Signal Output: Provides accurate vehicle speed/RPM signal to ECU, ensuring correct speedometer/RPM display and engine control system operation.
Weather Resistance: Sealed design, oil-proof, water-resistant, and vibration-resistant for harsh operating environments.
Plug and Play: Direct replacement for faulty original sensor, no additional modifications required.

⚠️ Common Failure Symptoms:

Speedometer not working or displaying incorrectly
Tachometer (RPM) not working or displaying incorrectly
Cruise control inoperative (if equipped)
Engine warning light illuminated with speed/RPM sensor related fault codes
Rough shifting (some models use speed signal for shift assistance)

✅ Service Tip: When the speed/RPM sensor fails, it typically requires replacement. Before installation, check the sensor mounting hole for metal debris or contamination, and clean the sensor sensing face. Do not overtighten during installation to avoid damaging the sensor housing. After installation, start the engine and test drive to verify speedometer and tachometer function.

⚠️ Installation Note: Disconnect the battery negative terminal before installation. Remove the old sensor and clean the mounting hole. Apply a small amount of oil to the new sensor O-ring, then insert into the mounting hole and tighten the mounting bolt to the torque specified in your service manual. Connect the electrical connector, ensuring it locks securely. Reconnect the battery and test sensor function.
