Front Output Shaft - Model MICF0180-062301
CFMoto front output shaft, CF500 output shaft, CF600 output shaft, 0180-062301, CF188-062301, CF188 parts, 196S-B parts, 196S-C parts, X6 transmission, U6 transmission, Z6 transmission, CFMoto driveline, ATV output shaft, UTV transmission parts  OEM quality front output shaft for CFMoto 500cc/600cc ATVs and UTVs. Compatible with CF188, CF188-A/B/C engines (2010-2017) and 196S-B/C engines (2010-2017). Features 22T/23mm driven bevel gear end, 14T/25mm coupler end, 32.5cm total length. Replaces part

Front Output Shaft

  • Brand: Mortch Motor
  • Product Code: MICF0180-062301
  • Product Viewed: 5
    •
  • Availability: Pre-Order
    • Pre-Order
  • Weight: 0.96kg
    •

0 reviews / Write a review

  • US$14.90


Shipping To：
More Quotes
Qty

Pre-Order

CFMoto Front Output Shaft

Replaces OEM: 0180-062301 / CF188-062301

Specs: Total Length 32.5cm / Driven Bevel Gear End 22T/23mm / Front Transmission Output End 14T/25mm / Thread 15mm

Compatible with CFMoto 500cc / 600cc engines (2010-2017)

📋 Overview

This Front Output Shaft is an important transmission component of the CFMoto 4WD system, responsible for transferring power from the transmission to the front differential to enable front wheel drive. This is a high-quality OEM replacement part, directly replacing OEM part numbers 0180-062301 / CF188-062301.

This output shaft has a total length of 32.5cm, with a driven bevel gear end of 22 teeth/23mm, a front transmission output end (for driveshaft connection) of 14 teeth/25mm, and a 15mm thread. It is suitable for CFMoto 500cc and 600cc engines, covering CF188, CF188-A, CF188-B, CF188-C, 196S-B(U6), 196S-B(X6), and 196S-C engine series, model years 2010-2017.

Detailed Specifications:

  • Total Length: 32.5cm (325mm)
  • Driven Bevel Gear End: 22 Teeth / 23mm Diameter
  • Front Transmission Output End (Driveshaft Connection): 14 Teeth / 25mm Diameter
  • Thread Specification: 15mm

✨ OEM Quality: Manufactured from high-strength alloy steel with precision machining and heat treatment, providing excellent strength and wear resistance for reliable 4WD system operation.

📐 Part Number Cross Reference
Current Part Number 0180-062301
Old Part Number CF188-062301
🔧 Detailed Engine Fitment List
🔩 196S-B(U6) 600cc Engine
  • ENGINE 2011 196S-B(U6) 600cc
  • ENGINE 2012 196S-B(U6) 600cc
  • ENGINE 2013 196S-B(U6) 600cc
  • ENGINE 2014 196S-B(U6) 600cc
  • ENGINE 2015 196S-B(U6) 600cc
🔩 196S-B(X6) 600cc Engine
  • ENGINE 2010 196S-B(X6) 600cc
  • ENGINE 2011 196S-B(X6) 600cc
  • ENGINE 2012 196S-B(X6) 600cc
  • ENGINE 2013 196S-B(X6) 600cc
  • ENGINE 2014 196S-B(X6) 600cc
  • ENGINE 2015 196S-B(X6) 600cc
  • ENGINE 2016 196S-B(X6) 600cc
  • ENGINE 2017 196S-B(X6) 600cc
🔩 196S-C 600cc Engine
  • ENGINE 2010 196S-C 600cc
  • ENGINE 2011 196S-C 600cc
  • ENGINE 2012 196S-C 600cc
  • ENGINE 2013 196S-C 600cc
  • ENGINE 2014 196S-C 600cc
  • ENGINE 2015 196S-C 600cc
  • ENGINE 2016 196S-C 600cc
  • ENGINE 2017 196S-C 600cc
🔩 CF188 500cc Engine
  • ENGINE 2010 CF188 500cc
  • ENGINE 2011 CF188 500cc
  • ENGINE 2012 CF188 500cc
  • ENGINE 2013 CF188 500cc
  • ENGINE 2014 CF188 500cc
  • ENGINE 2015 CF188 500cc
  • ENGINE 2016 CF188 500cc
  • ENGINE 2017 CF188 500cc
🔩 CF188-A 500cc Engine
  • ENGINE 2010 CF188-A 500cc
  • ENGINE 2011 CF188-A 500cc
  • ENGINE 2012 CF188-A 500cc
  • ENGINE 2013 CF188-A 500cc
  • ENGINE 2014 CF188-A 500cc
  • ENGINE 2015 CF188-A 500cc
🔩 CF188-B 500cc Engine
  • ENGINE 2010 CF188-B 500cc
  • ENGINE 2011 CF188-B 500cc
  • ENGINE 2012 CF188-B 500cc
  • ENGINE 2013 CF188-B 500cc
  • ENGINE 2014 CF188-B 500cc
  • ENGINE 2015 CF188-B 500cc
  • ENGINE 2016 CF188-B 500cc
🔩 CF188-C 500cc Engine
  • ENGINE 2011 CF188-C 500cc
  • ENGINE 2012 CF188-C 500cc
  • ENGINE 2013 CF188-C 500cc
  • ENGINE 2015 CF188-C 500cc

📌 Compatibility Note: This front output shaft fits the CFMoto 500cc and 600cc engines listed above, model years 2010-2017. Due to possible variations between different engine models and years, it is recommended to verify your original output shaft specifications before purchasing.

⚙️ Product Features
  • Direct OEM Replacement: Perfectly matches CFMoto OEM part numbers 0180-062301 / CF188-062301, ensuring precise fitment.
  • High-Strength Material: Made from high-quality alloy steel with heat treatment for excellent torsional strength and wear resistance.
  • Precision Machining: Splines on both ends are precision-machined for perfect配合 with the driven bevel gear and driveshaft, ensuring smooth power transmission.
  • Precise Dimensions: Total length 32.5cm with accurate tooth counts and diameters to ensure proper 4WD system operation.
  • Critical Transmission Component: Core component of the 4WD system ensuring reliable power delivery to the front axle.
✅ Importance of Front Output Shaft Replacement: The front output shaft is a critical component of the 4WD system,承受ing tremendous torque over time. It may experience spline wear, shaft bending, or breakage, leading to 4WD failure, transmission noise, and increased vibration. If you notice 4WD system noise, reduced front axle power, or driveshaft looseness, inspect and replace the front output shaft promptly to prevent more severe transmission damage.
⚠️ Verify Before Ordering: Please ensure your engine model and year are listed in the fitment guide and verify the output shaft specifications (Total Length 32.5cm / Driven Bevel Gear End 22T/23mm / Front Output End 14T/25mm) match your original component. Pay attention to oil seal position during installation. Professional installation is recommended.
🔧 Compatibility Notice
  • Please verify that this part fits your specific vehicle model and year. Many vehicles share similar names but use different components depending on year or market region.
  • We strongly recommend cross-checking with your vehicle's owner's manual or contacting us for confirmation before placing your order.
📄 Product Disclaimer
  • Product images, measurements, and descriptions are for reference only. Slight variations in color or appearance may occur due to manufacturing batches or photography lighting—functional specifications remain identical to the ordered part.
  • Professional installation is mandatory. Mortch Motor assumes no liability for damages, injuries, or losses resulting from improper installation, misuse, unauthorized modification, or abnormal operation.
💰 Import Duties & Taxes
  • All listed prices EXCLUDE shipping costs, import duties, taxes, and customs clearance fees. These charges (if applicable) are determined and collected by your local customs authority and are solely the buyer's responsibility.
  • In case of return due to unpaid duties/taxes or refusal to clear customs, the buyer shall bear the original shipping cost, return shipping fees, and any associated administrative charges deducted from the refund.
📌 Order Confirmation: By completing your purchase, you acknowledge that you have read, understood, and agreed to all terms above. For any questions, please contact our support team prior to ordering.
