O-Ring 88x2.5

Brand: Mortch Motor
Product Code: MICF0180-062205

Product Viewed: 2

Availability: In Stock

Weight: 0.01kg

0 reviews / Write a review

US$0.50

Shipping To：

More Quotes

CFMoto O-Ring 88×2.5 for Driven Bevel Gear Bearing Seat

Replaces OEM: 0180-062205 / CF188-062205

Specs: 88×2.5mm (OD × Cross-section)

Compatible with CFMoto 400cc / 500cc / 550cc / 600cc / 800cc / 850cc engines

📋 Overview

This O-Ring is an important sealing component installed on the driven bevel gear bearing seat, preventing oil leakage and keeping external contaminants out of the transmission system. This is a high-quality OEM replacement part, directly replacing OEM part numbers 0180-062205 / CF188-062205.

This O-ring measures 88×2.5mm (OD × cross-section) and is suitable for various CFMoto engine series with displacements of 400cc, 500cc, 550cc, 600cc, 800cc, and 850cc, featuring 191Q, 191R, 191S, 196S-B, 196S-C, 2V91W, and CF188 engines.

Specifications: 88mm(OD) × 2.5mm(Cross-section) | Oil-resistant NBR

✨ OEM Quality: Manufactured from high-quality oil-resistant NBR (Nitrile Rubber) with excellent oil resistance, aging resistance, and sealing performance, ensuring long-term reliable transmission operation.

📐 Part Number Cross Reference

Current Part Number 0180-062205

Old Part Number CF188-062205

🔧 Engine Compatibility

191Q 400cc Engine: 2014-2018

191R FOR CF500AU-7S&7L 550cc Engine: 2016-2018

191R-C FOR CF500AU-6B 550cc Engine: 2016-2018

191R-C FOR CF500AU-8S/8L 550cc Engine: 2016-2018

191R-U550 550cc Engine: 2013-2018

191R-X550 550cc Engine: 2014-2018

191R-Z550 550cc Engine: 2014-2018

191S 600cc Engine: 2018

196S-B(U6) 600cc Engine: 2011-2015

196S-B(X6) 600cc Engine: 2010-2017

196S-C 600cc Engine: 2010-2017

2V91W FOR CF800ATR-2 800cc Engine: 2016-2018

2V91W FOR CF800UTR 800cc Engine: 2017-2018

2V91W FOR CF800UTR-2 800cc Engine: 2017-2018

2V91W(U8) 800cc Engine: 2012-2018

2V91W(Z8) 800cc Engine: 2012-2018

2V91W-A 850cc Engine: 2017-2018

2V91W-S 800cc Engine: 2016-2018

CF188 500cc Engine: 2010-2017

CF188-A 500cc Engine: 2010-2015

CF188-B 500cc Engine: 2010-2016

CF188-C 500cc Engine: 2011-2013, 2015

📌 Compatibility Note: This O-ring fits the various CFMoto engine series listed above. Due to the wide range of engine models and years, it is recommended to verify your original O-ring specification is 88×2.5mm before purchasing.

⚙️ Product Features

Direct OEM Replacement: Perfectly matches CFMoto OEM part numbers 0180-062205 / CF188-062205, ensuring precise fitment.
High-Quality Material: Made from oil-resistant NBR (Nitrile Rubber) with excellent resistance to oil, aging, and wear.
Precise Dimensions: 88×2.5mm precision size ensures perfect配合 with the bearing seat for reliable sealing.
Leak Prevention: Effectively prevents oil leakage, protecting the transmission system.
Contamination Protection: Keeps external dust and contaminants out of the transmission system, extending component life.

✅ Importance of O-Ring Replacement: Although small, O-rings play a critical sealing role. Over time, they can age, harden, crack, or wear, causing oil leaks - not only reducing oil levels but also potentially damaging the environment. External contaminants entering the transmission system accelerate gear and bearing wear. If you notice oil residue near the transmission, inspect and replace aging O-rings promptly to protect the transmission system.

⚠️ Verify Before Ordering: Please ensure your engine model is listed in the compatibility guide and verify the O-ring specification is 88×2.5mm. Ensure proper installation in the groove without twisting or damage; apply a small amount of oil before installation. Professional installation is recommended.

🔧 Compatibility Notice

Please verify that this part fits your specific vehicle model and year. Many vehicles share similar names but use different components depending on year or market region.
We strongly recommend cross-checking with your vehicle's owner's manual or contacting us for confirmation before placing your order.
