Driven Bevel Gear Adjusting Gasket - Model MICF0800-062203
CFMoto adjusting gasket, 0800-062203, driven bevel gear shim, differential shim, gasket set, CF400 shim, CF500 shim, CF600 shim, CF800 shim, CF1000 shim, CForce parts, ZForce parts, UForce parts  CFMoto Driven Bevel Gear Adjusting Gasket Shim Set | 0.1-0.5mm | 0800-062203  OEM CFMoto driven bevel gear adjusting gasket/shim set (0.1-0.5mm thickness). Part# 0800-062203. Universal fit for CF400-1000 CForce, ZForce, UForce ATVs & UTVs. Differential adjustment shim. Fast shipping.

Driven Bevel Gear Adjusting Gasket

  • Brand: Mortch Motor
  • Product Code: MICF0800-062203
  • Product Viewed: 6
    •
  • Availability: 3
  • Weight: 0.01kg
    •

0 reviews / Write a review

  • US$2.13


Shipping To：
More Quotes
Qty

Buy Now
Share this product
QQWeiboFacebookWeChatXWhatsAppEmailBlueskyLinkedInCopy LinkPinterestTelegram
Loading...

CFMoto Driven Bevel Gear Adjusting Shims

Base Part Number: 0800-062203

Product Type: Adjusting Shim | Differential/Transmission Clearance Adjustment

Available Thickness: 0.1mm, 0.2mm, 0.3mm, 0.4mm, 0.5mm

Compatible with CFMoto 400cc - 1000cc ATV and SSV models, covering 191Q, 191R, 191S, 2V91 series engines

📋 Product Overview

This product is a genuine CFMoto specification driven bevel gear adjusting shim, base part number 0800-062203. These shims are used to precisely adjust the position of the driven bevel gear (ring gear) to ensure optimal backlash and contact pattern with the drive bevel gear (pinion gear). Proper adjustment is critical for smooth drivetrain operation, noise reduction, and extended gear life.

Available Thicknesses and Corresponding Part Numbers:

  • 0.1mm: 0800-062203
  • 0.2mm: 0800-062203-0001
  • 0.3mm: 0800-062203-0002
  • 0.4mm: 0800-062203-0003
  • 0.5mm: 0800-062203-0004

🔧 Genuine Quality Assurance: Manufactured from high-quality steel with precise thickness and flat surfaces, strictly following CFMoto original technical standards. Ensures accurate and reliable results when adjusting drivetrain clearances.

📐 Specifications

Base Part Number: 0800-062203

Product Type: Adjusting Shim

Material: High-Quality Alloy Steel

Available Thickness: 0.1mm / 0.2mm / 0.3mm / 0.4mm / 0.5mm

Precision: High precision, tightly controlled thickness tolerance

Compatible Engine Series: 191Q, 191R, 191S, 2V91

🔧 Complete Compatible Models List
🏍️ 1000cc Series (CForce 1000, ZForce 1000, UForce 1000)
  • ATV CF1000ATR CForce 1000 2V91Y-X10 (incl. GD, KSR, SS variants)
  • ATV CF1000ATR-2 CForce 1000 2V91Y-X10
  • ATV CF1000AU CForce 1000 2V91Y-X10 (incl. AU, CA, RU, ST, US, government variants)
  • ATV CF1000AU-F CForce 1000 2V91Y-C (incl. GD, KSR variants)
  • ATV CF1000AZ CForce 1000 2V91Y-C (incl. CA, US variants)
  • ATV CF1000AZ-2 CForce 1000 2V91Y-C (incl. RU, US variants)
  • SSV CF1000STR-3L ZForce 1000 2V91W-D (incl. GD variants)
  • SSV CF1000SU-3 ZForce 1000 (incl. US variant)
  • SSV CF1000SU-3A ZForce 1000 (incl. US variant)
  • SSV CF1000SU-3L ZForce 1000 (incl. US variant)
  • SSV CF1000SU-D ZForce 950 H.O.EX/ZForce 1000 Sport R 2V91Y-D (incl. AU, RU, ST, US variants)
  • SSV CF1000SU-E ZForce 1000 (incl. ST variant)
  • SSV CF1000SZ-3 ZForce 1000 (incl. CA, US variants)
  • SSV CF1000SZ-3A ZForce 950 Sport/ZForce 1000 Sport (incl. AU, CA, ST, US variants)
  • SSV CF1000SZ-3L ZForce 950 Sport 4 2V91Y-D (incl. AU, CA, RU, ST, US variants)
  • SSV CF1000SZ-D ZForce 950 HO EX (incl. CA, US variants)
  • SSV CF1000SZ-E ZForce 950 HO Sport (incl. CA, US variants)
  • SSV CF1000US ZForce 1000EX 2V91Y-Z10 (incl. AU, RU variants)
  • SSV CF1000US-2 ZForce 1000 2V91Y-Z1000 (incl. CA, US variants)
  • SSV CF1000US-A ZForce 950 Sport/ZForce 1000 Sport 2V91Y-Z10 (incl. CA, US variants)
  • POLICE MOTORCYCLE CF1000US-J ZForce 1000
  • SSV CF1000UTR-2 ZForce 1000 2V91Y-Z1000 (incl. GD variant)
  • SSV CF1000UTR-6(T1b) ZForce 1000 2V91W-D (incl. GD, KSR, SS variants)
  • SSV CF1000UTR-B ZForce 1000 Sport 2V91Y-Z10 (incl. GD, KSR, SS variants)
  • SSV CF1000UTR-C ZForce 1000 Sport 2V91Y-D (incl. GD, KSR, SS variants)
  • UTV CF1000UTR-3 UForce 1000 2V91Y-U10 (incl. GD, KSR, SS variants)
  • UTV CF1000UTR-5 UForce 1000 2V91Y-U10 (incl. GD, KSR, SS variants)
  • UTV CF1000UU UForce 1000 2V91Y-U10 (incl. AU, CA, RU, ST, US variants)
  • UTV CF1000UU-2 UForce 1000 XL 2V91Y-U10 (incl. AU, RU, ST, US variants)
  • UTV CF1000UZ UForce 1000 2V91Y-U10 (incl. CA, US variants)
  • UTV CF1000UZ-2 UForce 1000 XL 2V91Y-U10 (incl. CA, US variants)
  • UTV CF1000UZ-2A UForce 1000 2V91Y-U10 (incl. US variant)
  • UTV CF1000UZ-A UForce 1000 2V91Y-U10 (incl. US variant)
🏍️ 800/850cc Series (CForce 800/850, ZForce 800, UForce 800, X8)
  • ATV CF800-2 X8 2V91W(X8)
  • ATV CF800ATR CForce 800 2V91W(X8)
  • ATV CF800ATR-2 CForce 800 2V91W for CF800ATR-2
  • ATV CF800ATR-5 CForce 800 2V91W for CF800ATR-2
  • ATV CF800AU-2B CForce 800 2V91W-S
  • SSV CF800 ZForce 800EX 2V91W(Z8) (incl. CA, US variants)
  • SSV CF800US-A ZForce 800 Trail 2V91W(Z8) (incl. CA, US variants)
  • SSV CF800UTR ZForce Z8-EX 2V91W for CF800UTR
  • SSV CF800SU-2 ZForce 800 Trail 2V91W-B (incl. US variant)
  • SSV CF800SZ-2 ZForce 800 Trail 2V91W-B (incl. AU, CA, ST, US variants)
  • UTV CF800-3 UForce 800 2V91W(U8) (incl. CA, US variants)
  • UTV CF800UTR-2 UForce 800 2V91W (incl. GD, KSR, SS variants) for CF800UTR-2
  • UTV CF800UU-A UForce 800 2V91W(U8) (incl. AU, KSR variants)
  • ATV CF800ATR-3 CForce 850XC 2V91W-A (incl. GD, KSR, SS variants)
  • ATV CF800AU-2A CForce 850XC 2V91W-A (incl. AU, CA, RU, ST, US, KSR variants)
  • ATV CF800AU-2AF CForce 800XC/850XC 2V91W-D (incl. KSR variants)
  • ATV CF800AZ-2A CForce 800XC 2V91W-D (incl. CA, US variants)
  • ATV CF800AZ-3 CForce 800XC 2V91W-D (incl. RU, US variants)
🏍️ 600/625cc Series (CForce 600/625, UForce 600)
  • ATV CF600ATR-2L CForce 625 Touring 191S (incl. T3b, GD, KSR, SS variants)
  • ATV CF600ATR-2LC CForce 625 Touring 191S-B (incl. GD, KSR, SS variants)
  • ATV CF600ATR-2S CForce 625 191S (incl. T3b, GD, KSR, SS variants)
  • ATV CF600ATR-2SC CForce 625 191S-B (incl. GD, SS variants)
  • ATV CF600ATR-L CForce 625 191S (incl. T3a, T3b, GD variants)
  • ATV CF600AU-3L CForce 600 Touring/625 Touring 191S (incl. AU, CA, RU, US, KSR variants)
  • ATV CF600AU-3LA CForce 600 Touring/625 Touring 191S-A (incl. AU, RU, ST, US variants)
  • ATV CF600AU-3LF CForce 600 Touring/625 Touring 191S-A (incl. GD, KSR variants)
  • ATV CF600AU-3S CForce 600/625 191S (incl. AU, CA, RU, US, KSR variants)
  • ATV CF600AU-3SA CForce 600 191S (incl. AU, RU, US variants)
  • ATV CF600AU-3SF CForce 600 191S-A (incl. KSR variants)
  • ATV CF600AU-L CForce 600 191S (incl. EU168, International, US, X6 police variants)
  • ATV CF600AZ-3L CForce 600 191S (incl. CA, US variants)
  • ATV CF600AZ-3LA CForce 600 Touring 191S (incl. CA, US variants)
  • ATV CF600AZ-3S CForce 600 191S (incl. CA, US variants)
  • ATV CF600AZ-3SA CForce 600 191S-B (incl. CA, US variants)
  • UTV CF600UTR(T1b) UForce 600 191S-U6 (incl. GD, KSR, SS variants)
  • UTV CF600UU UForce 600 191S-U6 (incl. AU, ST, US variants)
  • UTV CF600UZ UForce 600 191S-U6 (incl. CA, US variants)
🏍️ 500/550cc Series (CForce 500/520/550, ZForce 500/550, UForce 550, COBALT)
  • ATV CF500ATR CForce 520 191R-X550
  • ATV CF500ATR-2L CForce 520L 191R-X550 (incl. T3a, T3b, GD, KSR, SS variants)
  • ATV CF500ATR-2LC CForce 520L 191R-X550
  • ATV CF500ATR-2S CForce 520S 191R-X550 (incl. T3a, T3b, GD, SS variants)
  • ATV CF500ATR-2SC CForce 520S 191R-X550
  • ATV CF500ATR-3 CForce 520 191R-X550 (incl. T3a variant)
  • ATV CF500ATR-5L(T3b) COBALT MAX T3 191R for CF500ATR-5L&5S
  • ATV CF500ATR-5S(T3b) COBALT T3 191R for CF500ATR-5L&5S
  • ATV CF500ATR-9L CForce 520 L 191R-E (incl. T3a, T3b, GD, KSR, SS variants) for CF500AU-9L/9S
  • ATV CF500ATR-9S CForce 550 191R-E (incl. T3a, T3b, GD, KSR, SS variants) for CF500AU-9L/9S
  • ATV CF500ATR-11L CForce 520L 191R-E (incl. SS variant) for CF500AU-9L/9S
  • ATV CF500ATR-11S CForce 520S 191R-E for CF500AU-9L/9S
  • ATV CF500ATR-A CForce 550 191R-X550
  • ATV CF500AU-6B CForce 550 191R-C for CF500AU-6B
  • ATV CF500AU-6L CForce 550 191R-X550 (incl. CA variant)
  • ATV CF500AU-7A CForce 520S 191R for CF500AU-7S&7L
  • ATV CF500AU-7C CForce 520L 191R (incl. KSR variants) for CF500AU-7S&7L
  • ATV CF500AU-7L CForce 520L 191R for CF500AU-7S&7L
  • ATV CF500AU-7LF CForce 520L 191R-E (incl. KSR variants)
  • ATV CF500AU-7S CForce 520 S 191R (incl. AU, CA, US variants) for CF500AU-7S&7L
  • ATV CF500AU-7SF CForce 500S/520S 191R-E (incl. GD variant)
  • ATV CF500AU-8L COBALT MAX L7e CF500AU-8S/8L
  • ATV CF500AU-8S COBALT L7e CF500AU-8S/8L
  • ATV CF500AU-9S CForce 550 191R-E (incl. GD variant) for CF500AU-9L/9S
  • ATV CF500AU-9L CForce 520 L 191R-E (incl. GD, KSR, RU, ST variants) for CF500AU-9L/9S
  • ATV CF500AU-10S CForce 550 191R-E (incl. US variant)
  • ATV CF500AZ-9S CForce 500/520 191R (incl. AU, CA, US variants) for CF500AU-9L/9S
  • ATV CF500AZ-10S CForce 500/520 191R (incl. CA, US variants) for CF500AU-9L/9S
  • SSV CF500US ZForce 500 Trail 191R-Z550 (incl. CA, US variants)
  • SSV CF500US-EX ZForce 550EX 191R-Z550
  • SSV CF500UTR ZForce 550EX 191R-Z550 (incl. T1a, T1b, GD, SS variants)
  • UTV CF500UTR-2 UForce 550 191R-U550 (incl. GD variant)
  • UTV CF500UU UForce 550/500 191R-U550 (incl. CA, US variants)
🏍️ 400/450cc Series (CForce 400/450, IRON, GOES TERROX 400)
  • ATV CF400ATR CForce 450 191Q
  • ATV CF400ATR-2L CForce 450L 191Q (incl. T3a, T3b, KSR, SS variants)
  • ATV CF400ATR-2S CForce 450S 191Q (incl. T3a, T3b, GD, KSR, SS variants, including versions for CF400ATR-4L/4S)
  • ATV CF400ATR-3L CForce 450L 191Q (incl. T3a, T3b, KSR, SS variants) for CF400AU-3L/3S
  • ATV CF400ATR-3S CForce 450S 191Q (incl. T3a, T3b, GD, KSR, SS variants) for CF400AU-3L/3S
  • ATV CF400ATR-4L GOES TERROX 400L 191Q (incl. SS variant) for CF400AU-3L/3S
  • ATV CF400ATR-4S GOES TERROX 400S 191Q for CF400AU-3L/3S
  • ATV CF400ATR-5L(T3b) IRON MAX T3 191Q
  • ATV CF400ATR-5S(T3b) IRON T3 191Q
  • ATV CF400ATR-L CForce 450L 191Q
  • ATV CF400AU CForce 400S/450S 191Q (incl. AU, CA, US, X4 police variants)
  • ATV CF400AU-2L IRON MAX L7e 191Q
  • ATV CF400AU-2S IRON L7e 191Q
  • ATV CF400AU-3L CForce 450L 191Q-A for CF400AU-3L/3S
  • ATV CF400AU-3S CForce 450S 191Q-A (incl. GD, KSR variants) for CF400AU-3L/3S
  • ATV CF400AU-6S CForce 450S 191Q (incl. US variant)
  • ATV CF400AU-A CForce 450S 191Q (incl. KSR variants)
  • ATV CF400AU-B CForce 450L 191Q (incl. KSR variants)
  • ATV CF400AU-G CForce 450L 191Q
  • ATV CF400AU-L CForce 400L/450L 191Q (incl. CA, RU variants)
  • ATV CF400AU-LF CForce 450L 191Q-A
  • ATV CF400AU-SF CForce 450S 191Q-A (incl. GD, KSR variants)
  • ATV CF400AZ-3L CForce 450L 191Q (incl. CA, RU, ST variants)
  • ATV CF400AZ-3S CForce 450S 191Q (incl. AU, CA, ST, US variants) for CF400AU-3L/3S
  • ATV CF400AZ-6L CForce 450L 191Q (incl. CA variant)
  • ATV CF400AZ-6S CForce 450S 191Q (incl. CA, US, CLS variants)

📌 Compatibility Note: This adjusting shim fits all CFMoto models listed above. Different suffixes indicate configuration or regional variations; this product remains compatible. Please select the appropriate thickness based on your vehicle and engine model. If your vehicle is not listed, please contact customer service for confirmation.

⚙️ Product Features
  • OEM Matching: Part numbers correspond exactly to the CFMoto official parts system, ensuring direct replacement.
  • Multiple Thickness Options: Available in 5 thicknesses from 0.1mm to 0.5mm to meet precise adjustment requirements.
  • Precision Manufacturing: Manufactured using high-precision stamping or cutting processes with uniform thickness and flat, burr-free surfaces.
  • Quality Material: Made from high-quality alloy steel or spring steel with good strength and wear resistance.
  • Surface Treatment: Rust-resistant surface treatment for long-term storage without corrosion.
🔧 Important Installation Note: Adjusting shims are used for internal differential or transmission clearance adjustments. Replacement requires specialized knowledge and tools. Professional installation by an experienced technician is highly recommended. Key considerations:
  • Record the thickness and installation position of the original shims before disassembly.
  • Thoroughly clean the mounting surfaces to ensure they are free of oil and debris.
  • Use a dial indicator or specialized tools to measure gear backlash and contact pattern.
  • Select the appropriate thickness shim combination according to the clearance specifications in the official service manual.
⚠️ Ordering Information: This product is a driven bevel gear adjusting shim, base part number 0800-062203, available in thicknesses from 0.1mm to 0.5mm. Please confirm the complete part number corresponding to the required thickness when ordering. Minor differences may exist between different years or batches. If you have questions about compatibility, please contact customer service.
🔧 Compatibility Notice
  • Please verify that this part fits your specific vehicle model and year. Many vehicles share similar names but use different components depending on year or market region.
  • We strongly recommend cross-checking with your vehicle's owner's manual or contacting us for confirmation before placing your order.
📄 Product Disclaimer
  • Product images, measurements, and descriptions are for reference only. Slight variations in color or appearance may occur due to manufacturing batches or photography lighting—functional specifications remain identical to the ordered part.
  • Professional installation is mandatory. Mortch Motor assumes no liability for damages, injuries, or losses resulting from improper installation, misuse, unauthorized modification, or abnormal operation.
💰 Import Duties & Taxes
  • All listed prices EXCLUDE shipping costs, import duties, taxes, and customs clearance fees. These charges (if applicable) are determined and collected by your local customs authority and are solely the buyer's responsibility.
  • In case of return due to unpaid duties/taxes or refusal to clear customs, the buyer shall bear the original shipping cost, return shipping fees, and any associated administrative charges deducted from the refund.
📌 Order Confirmation: By completing your purchase, you acknowledge that you have read, understood, and agreed to all terms above. For any questions, please contact our support team prior to ordering.
