Start Relay

Brand: Mortch Motor
Product Code: MICF9CR6-150310

Product Viewed: 2

Availability: In Stock

Weight: 0.16kg

Packing Size: 10.00 x 8.00 x 4.00cm

0 reviews / Write a review

US$6.67 24 SOLD

Shipping To：

More Quotes

This Starter Relay / Starter Solenoid applies to (and is not limited to) 250cc to 600cc electric start engines. This relay operates in the same way as other non-fuse based relays and using a 20A in-line fuse is one of the best ways to provide additional circuit protection. Bolt studs are 2cm apart center to center. This Starter Relay is most commonly used for Chironex Spartan 500cc and Chironex Spartan 600cc UTVs (4x4/2x4 and similar variations), Xinyang 500cc - 600cc ATVs and UTVs (4x4/2x4 and similar variations) as well as a range of CF Moto machines such as the CF500 ATV.

Most commonly used for (but not limited to) Chironex Spartan 500cc UTVs (4x4/2x4 and similar variations), Chironex Spartan 600cc UTVs (4x4/2x4 and similar variations), CF Moto 500cc and 600cc UTVs (4x4/2x4 and similar variations), Xinyang 500cc XY500UE, Xinyang 600cc XY600UE ATVs and UTVs (4x4/2x4 and similar variations).

Common Chironex model name is primarily listed as "Chironex 500cc or 600cc Spartan XUV or UTV", Common listed Chironex Spartan starter solenoid / starter relay part number is 31800-5000 and is listed as "STARTING RELAY" in their parts lists.

Common CFMOTO model names consist of variations of "CF Moto 400cc ATV", "CF Moto 500cc ATV", "CF Moto 600cc UTV", "CF Moto 600cc UTV", "CF Moto 600cc XUV", "CF moto 600cc 4x4" etc. Common listed CF Moto starter relay part number is 9010-150310-1000 with 'old part number' listed as 901-15.03.10-1 and formal description as "STARTER RELAY".

Common Xinyang model names consist of variations of "XY500UE" and "XY600UE", as well as a range of less formal names such as "Xinyang 500cc or 600cc UTV", "Xinyang 500cc or 600cc XUV", "Xinyang 500cc or 600cc ATV", "Xinyang 500cc/600cc 4x4/2x4" etc. Common listed Xinyang starter solenoid / starter relay part number is 31800-5000 and is listed as "STARTING RELAY" in their parts lists.

CF Moto listed parts number is 9CR6-150310

Starter Relay Testing Procedure

Put DC 12V between positive and negative terminal. Use multimeter to check if there is continuity between 2 contacts.

If multimeter clicks, there is continuity between contacts.

If DC 12V is removed, no continuity remains between contacts.

If both above 2 items are ok, it indicates the relay is good. Turn multimeter to DIODE mode.

CAUTION: The voltage loaded between terminals cannot exceed 2 minutes, otherwise, starter relay may overheat or burn.

Use multimeter to measure starter relay coil resistance, if the reading is out of specification, replace a new one.

Turn multimeter to 1×10Ω range.

Starter Relay Coil Resistance: 3Ω～5Ω

This may fits

ATV CF1000ATR CForce 1000
ATV CF1000AU CForce 1000 EPS Overland
ATV CF1000AU-F CForce 1000
ATV CF1000AZ CForce 1000 Overland
ATV CF400ATR CForce 450
ATV CF400ATR-2L(T3a) CForce 450L
ATV CF400ATR-2L(T3b) CForce 450L
ATV CF400ATR-2S(T3a) CForce 450S
ATV CF400ATR-2S(T3b) CForce 450S
ATV CF400ATR-3L(T3a) CForce 450 L
ATV CF400ATR-3L(T3b) CForce 450 L
ATV CF400ATR-3S(T3a) CForce 450
ATV CF400ATR-3S(T3b) CForce 450
ATV CF400ATR-4L GOES TERROX 400L
ATV CF400ATR-4S GOES TERROX 400S
ATV CF400ATR-L CForce 450L
ATV CF400AU CForce 400S/450S
ATV CF400AU-3L CForce 450L
ATV CF400AU-3LH CForce 450L
ATV CF400AU-3S CForce 450S
ATV CF400AU-3SH CForce 450S
ATV CF400AU-6S CForce 450S
ATV CF400AU-A CForce 450S
ATV CF400AU-B CForce 450L
ATV CF400AU-G GOES TERROX 400S
ATV CF400AU-L CForce 400L/450L
ATV CF400AU-LA GOES TERROX 400L
ATV CF400AU-LF CForce 450L
ATV CF400AU-SF CForce 450S
ATV CF400AZ-3L CForce 400 TOURING/CForce 450 L
ATV CF400AZ-3S CForce 400/CForce 450
ATV CF400AZ-6L CForce 450L
ATV CF400AZ-6S CForce 450S
ATV CF500ATR CForce 520
ATV CF500ATR-11L GOES TERROX 500L
ATV CF500ATR-11S GOES TERROX 500S
ATV CF500ATR-2L(T3a) CForce 520L
ATV CF500ATR-2L(T3b) CForce 520L
ATV CF500ATR-2S(T3a) CForce 520S
ATV CF500ATR-2S(T3b) CForce 520S
ATV CF500ATR-3 CForce 520
ATV CF500ATR-3(T3a) CForce 520
ATV CF500ATR-9L(T3a) CForce 520 L
ATV CF500ATR-9L(T3b) CForce 520 L
ATV CF500ATR-9S(T3a) CForce 550
ATV CF500ATR-9S(T3b) CForce 550
ATV CF500ATR-A CForce 550
ATV CF500AU-10S CForce 500 S
ATV CF500AU-6B CForce 550
ATV CF500AU-6L CForce 550
ATV CF500AU-7A CForce 520S
ATV CF500AU-7C CForce 520L
ATV CF500AU-7L CForce 520L
ATV CF500AU-7LA GOES TERROX 500L
ATV CF500AU-7LF CForce 520L
ATV CF500AU-7S CForce 520 S
ATV CF500AU-7SA GOES TERROX 500S
ATV CF500AU-7SF CForce 500S/CForce 520S
ATV CF500AU-9L CForce 520 L
ATV CF500AU-9LH CForce 520 L
ATV CF500AU-9S CForce 520/CForce 500
ATV CF500AU-9SH CForce 520
ATV CF500AZ-10S CForce 500 S
ATV CF500AZ-9S CForce 500/CForce 520
ATV CF600ATR-2L(T3b) CForce 625 Touring
ATV CF600ATR-2LC CForce 625 Touring
ATV CF600ATR-2S(T3b) CForce 625
ATV CF600ATR-2SC CForce 625
ATV CF600ATR-L(T3a) CForce 600
ATV CF600ATR-L(T3b) CForce 600
ATV CF600AU-3L CForce 600 Touring/625 Touring
ATV CF600AU-3LA CForce 600 Touring/625 Touring
ATV CF600AU-3LF CForce 600 Touring/625 Touring
ATV CF600AU-3S CForce 600/625
ATV CF600AU-3SA CForce 625 EPS
ATV CF600AU-3SF CForce 600
ATV CF600AU-L(EU168) CForce 600
ATV CF600AU-L(INTERNATIONAL) CForce 600
ATV CF600AU-L CForce 600 EPS
ATV CF600AZ-3L CForce 600
ATV CF600AZ-3LA CForce 600 Touring
ATV CF600AZ-3S CForce 600
ATV CF600AZ-3SA CForce 600
ATV CF800ATR-3 CForce 850XC
ATV CF800AU-2A CForce 850XC
ATV CF800AU-2AF CForce 800XC/CForce 850XC
ATV CF800AZ-2A CForce 800XC
ENGING(ONLY FOR ENGINE) 2V91W（艾普斯顿）
ENGING(ONLY FOR ENGINE) 2V91Y-X10（销售专用）
MOTORCYCLE CF400-12(CN4)
MOTORCYCLE CF400-13(CN4)
MOTORCYCLE CF400-5(CN4) 400GT
MOTORCYCLE CF400-5F(EU5)
MOTORCYCLE CF400-6(CN4)
MOTORCYCLE CF400-6(INTL)
MOTORCYCLE CF400-6(INTL-CHAMPION VERSION)
MOTORCYCLE CF400-6 400SR
MOTORCYCLE CF400-6F(EU5)
MOTORCYCLE CF400-6F(KTM)
MOTORCYCLE CF400-6H
MOTORCYCLE CF400-6H(CHAMPION VERSION)
MOTORCYCLE CF400-6US
MOTORCYCLE CF400-7(CN4)
MOTORCYCLE CF400-7(INTL)
MOTORCYCLE CF400-7
MOTORCYCLE CF400-7F(EU5)
MOTORCYCLE CF400-7F(KTM)
MOTORCYCLE CF400-7H
MOTORCYCLE CF400-7US
MOTORCYCLE CF400-9(CN4)
MOTORCYCLE CF400-9(CN4-CHAMPION VERSION)
MOTORCYCLE CF400-9(INTL)
MOTORCYCLE CF400-9(INTL-CHAMPION VERSION)
MOTORCYCLE CF400-9F(EU5)
MOTORCYCLE CF400-9F(KTM)
MOTORCYCLE CF400-B(CN4) 400NK
MOTORCYCLE CF400-B(INTL)
MOTORCYCLE CF400-BF(EU5)
MOTORCYCLE CF650-3C(CN4) 650MT
MOTORCYCLE CF650-3C(INTL)
MOTORCYCLE CF650-3F(EU5)
MOTORCYCLE CF650-3F(KTM)
MOTORCYCLE CF650-3US
MOTORCYCLE CF650-6A(CN4) 650TR-G
MOTORCYCLE CF650-7C(CN4) 650NK
MOTORCYCLE CF650-7C(INTL)
MOTORCYCLE CF650-7F(EU5)
MOTORCYCLE CF650-7F(KTM)
MOTORCYCLE CF650-7US
MOTORCYCLE CF650-8(CN4) 650GT
MOTORCYCLE CF650-8(INTL)
MOTORCYCLE CF650-8F(EU5)
MOTORCYCLE CF650-8F(KTM)
MOTORCYCLE CF700-9F(EU5)
MOTORCYCLE CF700-9F(INTL)
MOTORCYCLE CF700-9F(KTM)
MOTORCYCLE CF800-5 EXPLORE(CN4)
MOTORCYCLE CF800-5 EXPLORE(EU5)
MOTORCYCLE CF800-5 EXPLORE(INTL)
MOTORCYCLE CF800-5 EXPLORE(KTM)
MOTORCYCLE CF800-5(CN4)
MOTORCYCLE CF800-5(EU5)
MOTORCYCLE CF800-5(INTL)
MOTORCYCLE CF800-5(KTM)
MOTORCYCLE CF800-5A(CN4)
MOTORCYCLE CF800-5AUS
MOTORCYCLE CF800-5BUS
MOTORCYCLE CF800-5H
MOTORCYCLE CF800-5H(KTM)
MOTORCYCLE CF800-5US
MOTORCYCLE CF800-7(CN4)
MOTORCYCLE CF800-7(INTL)
MOTORCYCLE CF800-7A(CN4)
MOTORCYCLE CF800-7A(INTL)
MOTORCYCLE CF800-7F(EU5)
MOTORCYCLE CF800-7F(KTM)
MOTORCYCLE CF800-7FH
MOTORCYCLE CF800-7US
POLICE MOTORCYCLE CF1000AU公务车 CForce 1000 EPS Overland
POLICE MOTORCYCLE CF400-5(警改民)
POLICE MOTORCYCLE CF400AU（X4警车） CForce 400S
POLICE MOTORCYCLE CF400AU-3L(公务消防车) CForce 450L
POLICE MOTORCYCLE CF400AZ-3L(公务消防车) CForce 450L
POLICE MOTORCYCLE CF400J-3
POLICE MOTORCYCLE CF600AU-L（X6警车） CForce 600
POLICE MOTORCYCLE CF650-6A（民改警）
POLICE MOTORCYCLE CF650J-2B
POLICE MOTORCYCLE CF650J-3B
POLICE MOTORCYCLE CF650J-3B军援国宾车
POLICE MOTORCYCLE CF800AU-2A(公务车) CForce 850XC
POLICE MOTORCYCLE CF800J-5A
