Oil Seal 35x50x7

Brand: Mortch Motor
Product Code: MICF0800-062204

Product Viewed: 6

Availability: 47

Weight: 0.02kg

0 reviews / Write a review

US$5.33 5 SOLD

Shipping To：

More Quotes

Qty

Buy Now

Tell a Friend Ask a Question

CFMoto Oil Seal 35x50x7

Part Number: 0800-062204

Product Type: Oil Seal | Rotary Shaft Lip Seal

Specifications: ID 35mm x OD 50mm x Thickness 7mm

Compatible with CFMoto 400cc - 1000cc ATV, SSV and UTV models

📋 Product Overview

This product is a genuine CFMoto specification oil seal, part number 0800-062204, with dimensions 35mm x 50mm x 7mm. This oil seal is used for sealing rotating shafts to prevent lubricant leakage and block contaminants such as dust, mud, and water from entering. It is widely used in engines, transmissions, differentials, wheel hubs, and other components.

Specifications:

Inner Diameter: 35mm
Outer Diameter: 50mm
Thickness: 7mm
Type: Single lip with spring, metal case

🔧 Genuine Quality Assurance: Manufactured from high-quality NBR (Nitrile Butadiene Rubber) or FKM (Fluoroelastomer) with excellent oil resistance, wear resistance, and high-temperature performance. The metal case provides sturdy support for long-term reliable sealing.

📐 Specifications

Part Number: 0800-062204

Product Type: Oil Seal / Rotary Shaft Lip Seal

Dimensions: 35mm x 50mm x 7mm

Inner Diameter: 35mm

Outer Diameter: 50mm

Thickness: 7mm

🔧 Complete Compatible Models List

🏍️ 1000cc Series (CForce 1000, ZForce 1000, UForce 1000)

ATV CF1000ATR CForce 1000
ATV CF1000ATR-2 CForce 1000 TOURING
ATV CF1000ATR-2A CForce 1000 OVERLAND
ATV CF1000ATR-3 CForce 1000 MV
ATV CF1000ATR-3L CForce 1000
ATV CF1000AU CForce 1000 EPS Overland
ATV CF1000AU-2 CForce 1000 TOURING
ATV CF1000AU-F CForce 1000
ATV CF1000AZ CForce 1000 Overland
ATV CF1000AZ-2 CForce 1000 TOURING
ATV CF1000AZ-2A CForce 1000 OVERLAND
ATV CF1000AZ-3 CForce 1000 MV
POLICE MOTORCYCLE CF1000AU Government CForce 1000 EPS Overland
POLICE MOTORCYCLE CF1000US-J ZForce 1000
POLICE MOTORCYCLE CF1000UU-2(Police) UForce 1000 XL
SSV CF1000STR-3L ZForce 950 SPORT-4
SSV CF1000SU Z10
SSV CF1000SU-3 ZForce 950 TRAIL
SSV CF1000SU-3A ZForce 950 SPORT
SSV CF1000SU-3L ZForce 950 SPORT-4
SSV CF1000SU-D ZForce 950 H.O.EX/ZForce 1000 Sport R
SSV CF1000SU-E ZForce 950 H.0.SPORT
SSV CF1000SU-L Z10-4
SSV CF1000SZ Z10
SSV CF1000SZ-3 ZForce 950 TRAIL
SSV CF1000SZ-3A ZForce 950 SPORT
SSV CF1000SZ-3L ZForce 950 Sport 4
SSV CF1000SZ-D ZForce 950 HO EX
SSV CF1000SZ-E ZForce 950 HO Sport
SSV CF1000SZ-L Z10-4
SSV CF1000US ZForce 1000EX
SSV CF1000US-2 ZForce 1000
SSV CF1000US-A ZForce 950 Sport/ZForce 1000 Sport
SSV CF1000UTR-2 ZForce 1000
SSV CF1000UTR-6(T1b) ZForce 1000
SSV CF1000UTR-B ZForce 1000 Sport
SSV CF1000UTR-C ZForce 1000 Sport
UTV CF1000UTR-3 UForce 1000
UTV CF1000UTR-5 UForce 1000 XL
UTV CF1000UTR-8 UForce 1000 PRO(T1b)
UTV CF1000UTR-8K UForce 1000 PRO MAX(T1b)
UTV CF1000UTR-8L UForce 1000 PRO MAX(T1b)
UTV CF1000UU UForce 1000
UTV CF1000UU-2 UForce 1000 XL
UTV CF1000UU-8 UForce 1000 XL
UTV CF1000UU-8K UForce 1000 Pro Highland
UTV CF1000UU-8L U10 XL PRO
UTV CF1000UU-8LK U10 XL PRO HIGHLAND
UTV CF1000UZ UForce 1000
UTV CF1000UZ-2 UForce 1000 XL
UTV CF1000UZ-8 UForce U10 PRO
UTV CF1000UZ-8K UForce U10 PRO Highland
UTV CF1000UZ-8L UForce U10 PRO XL
UTV CF1000UZ-8LK
UTV CM1000UZ-2A UForce 1000 XL Alpine
UTV CM1000UZ-A UForce 1000 Alpine

🏍️ 800/850cc Series (CForce 800/850, ZForce 800, UForce 800)

ATV CF800ATR-3 CForce 850XC
ATV CF800ATR-5 CForce 850 TOURING
ATV CF800AU-2A CForce 850XC
ATV CF800AU-2AF CForce 800XC/CForce 850XC
ATV CF800AU-2B CForce 800
ATV CF800AU-3 CForce 850 TOURING
ATV CF800AZ-2A CForce 800XC
ATV CF800AZ-3 CForce 800 TOURING/CForce 850 TOURING
POLICE MOTORCYCLE CF800(Z8) ZForce 800EX
POLICE MOTORCYCLE CF800AU-2A(Government) CForce 800XC
SSV CF800 ZForce 800EX
SSV CF800SU-2 ZForce 800 Trail
SSV CF800SU-3 ZForce 800 SPROT
SSV CF800SZ-2 ZForce 800 Trail
SSV CF800SZ-3
SSV CF800US-A ZForce 800 Trail
SSV CF800UTR ZForce Z8-EX
UTV CF800-3 UForce 800
UTV CF800UTR-2 UForce 800
UTV CF800UTR-4 UForce 800 XL
UTV CF800UU-4 UForce 800 XL
UTV CF800UU-A UForce 800
UTV CF800UZ-4 UForce 800

🏍️ 600/625cc Series (CForce 600/625, UForce 600)

ATV CF600ATR-2L(T3b) CForce 625 Touring
ATV CF600ATR-2LC CForce 625 Touring
ATV CF600ATR-2S(T3b) CForce 625
ATV CF600ATR-2SC CForce 625
ATV CF600AU-3L CForce 600 Touring/625 Touring
ATV CF600AU-3LA CForce 600 Touring/625 Touring
ATV CF600AU-3LF CForce 600 Touring/625 Touring
ATV CF600AU-3LH CForce 600 Touring/625 Touring
ATV CF600AU-3S CForce 600/625
ATV CF600AU-3SA CForce 625 EPS
ATV CF600AU-3SF CForce 600
ATV CF600AU-3SH CForce 600
ATV CF600AU-L(EU168) CForce 600
ATV CF600AZ-3L CForce 600
ATV CF600AZ-3LA CForce 600 Touring
ATV CF600AZ-3S CForce 600
ATV CF600AZ-3SA CForce 600
POLICE MOTORCYCLE CF600AU-L(X6 Police) CForce 600
POLICE MOTORCYCLE CF600UU(Police) UForce 600
UTV CF600UTR(T1b) UForce 600
UTV CF600UU UForce 600
UTV CF600UZ UForce 600

🏍️ 500/550cc Series (CForce 500/520/550, ZForce 500/550, UForce 550, COBALT, GOES TERROX)

ATV CF500ATR-11L GOES TERROX 500L
ATV CF500ATR-11S GOES TERROX 500S
ATV CF500ATR-2L(T3a) CForce 520L
ATV CF500ATR-2L(T3b) CForce 520L
ATV CF500ATR-2S(T3a) CForce 520S
ATV CF500ATR-2S(T3b) CForce 520S
ATV CF500ATR-9L(T3a) CForce 520 L
ATV CF500ATR-9L(T3b) CForce 520 L
ATV CF500ATR-9S(T3a) CForce 550
ATV CF500ATR-9S(T3b) CForce 550
ATV CF500AU-10S CForce 500 S
ATV CF500AU-6B CForce 550
ATV CF500AU-7A CForce 520S
ATV CF500AU-7C CForce 520L
ATV CF500AU-7L CForce 520L
ATV CF500AU-7LA GOES TERROX 500L
ATV CF500AU-7LF CForce 520L
ATV CF500AU-7S CForce 520 S
ATV CF500AU-7SA GOES TERROX 500S
ATV CF500AU-7SF CForce 500S/CForce 520S
ATV CF500AU-8L COBALT MAX L7e
ATV CF500AU-8S COBALT L7e
ATV CF500AU-9L CForce 520 L
ATV CF500AU-9LH CForce 520 L
ATV CF500AU-9S CForce 520/CForce 500
ATV CF500AU-9SH CForce 520
ATV CF500AZ-10S CForce 500 S
ATV CF500AZ-9S CForce 500/CForce 520
SSV CF500US ZForce 500 Trail
SSV CF500US-EX ZForce 550EX
SSV CF500UTR(T1a) ZForce 550EX
SSV CF500UTR(T1b) ZForce 550EX
UTV CF500UTR-2 UForce 550
UTV CF500UU UForce 550

🏍️ 400/450cc Series (CForce 400/450, IRON, GOES TERROX 400)

ATV CF400ATR CForce 450
ATV CF400ATR-2L(T3a) CForce 450L
ATV CF400ATR-2L(T3b) CForce 450L
ATV CF400ATR-2S(T3a) CForce 450S
ATV CF400ATR-2S(T3b) CForce 450S
ATV CF400ATR-3L(T3a) CForce 450 L
ATV CF400ATR-3L(T3b) CForce 450 L
ATV CF400ATR-3S(T3a) CForce 450
ATV CF400ATR-3S(T3b) CForce 450
ATV CF400ATR-4L GOES TERROX 400L
ATV CF400ATR-4S GOES TERROX 400S
ATV CF400ATR-L CForce 450L
ATV CF400AU CForce 400S/450S
ATV CF400AU-2L IRON MAX L7e
ATV CF400AU-2S IRON L7e
ATV CF400AU-3L CForce 450L
ATV CF400AU-3LH CForce 450L
ATV CF400AU-3S CForce 450S
ATV CF400AU-3SH CForce 450S
ATV CF400AU-6S CForce 450S
ATV CF400AU-A CForce 450S
ATV CF400AU-B CForce 450L
ATV CF400AU-G GOES TERROX 400S
ATV CF400AU-L CForce 400L/450L
ATV CF400AU-LA GOES TERROX 400L
ATV CF400AU-LF CForce 450L
ATV CF400AU-SF CForce 450S
ATV CF400AZ-3L CForce 400 TOURING/CForce 450 L
ATV CF400AZ-3S CForce 400/CForce 450
ATV CF400AZ-6L CForce 450L
ATV CF400AZ-6S CForce 450S
POLICE MOTORCYCLE CF400AU(X4 Police) CForce 400S
POLICE MOTORCYCLE CF400AU-3L(Fire) CForce 450L
POLICE MOTORCYCLE CF400AZ-3L(Fire) CForce 450L

🏍️ Other Models

ATV CF650AZ-S
UTV CF200DUTR
UTV CF200DUU

📌 Compatibility Note: This oil seal fits all CFMoto models listed above. Different suffixes indicate configuration or regional variations; this product remains compatible. If your vehicle is not listed, please contact customer service for confirmation.

⚙️ Product Features

OEM Matching: Part number corresponds exactly to the CFMoto official parts system, ensuring direct replacement.
Precision Dimensions: Manufactured strictly to 35mm x 50mm x 7mm standard dimensions for perfect fit.
High-Quality Rubber Material: Made from premium NBR or FKM with excellent oil resistance, wear resistance, and high-temperature performance.
Metal Case: Internal metal case provides sturdy support to prevent deformation during installation and use.
Garter Spring: Lip includes a garter spring to maintain consistent sealing pressure throughout long-term use.

🔧 Important Installation Note: Oil seals are precision sealing components and correct installation is critical. Professional installation by an experienced technician is highly recommended. Key considerations:

Inspect the shaft and housing bore surfaces before installation to ensure they are smooth, free of burrs and scratches.
Apply a small amount of lubricant to the seal lip to prevent dry running during initial startup.
Use a proper installation tool to press the seal in evenly, avoiding hammer blows that could deform or damage the seal.
Ensure the seal is installed with the correct orientation (spring side facing the fluid).
Check that the seal is perpendicular to the shaft axis after installation, with no tilting.

⚠️ Ordering Information: This product is an oil seal, part number 0800-062204, dimensions 35mm x 50mm x 7mm. Minor differences may exist between different years or batches. If your vehicle is not listed above, or if you have questions about compatibility, please contact customer service with your VIN or engine model for confirmation.

🔧 Compatibility Notice

Please verify that this part fits your specific vehicle model and year. Many vehicles share similar names but use different components depending on year or market region.
We strongly recommend cross-checking with your vehicle's owner's manual or contacting us for confirmation before placing your order.

📄 Product Disclaimer

Product images, measurements, and descriptions are for reference only. Slight variations in color or appearance may occur due to manufacturing batches or photography lighting—functional specifications remain identical to the ordered part.
Professional installation is mandatory. Mortch Motor assumes no liability for damages, injuries, or losses resulting from improper installation, misuse, unauthorized modification, or abnormal operation.

💰 Import Duties & Taxes

All listed prices EXCLUDE shipping costs, import duties, taxes, and customs clearance fees. These charges (if applicable) are determined and collected by your local customs authority and are solely the buyer's responsibility.
In case of return due to unpaid duties/taxes or refusal to clear customs, the buyer shall bear the original shipping cost, return shipping fees, and any associated administrative charges deducted from the refund.

📌 Order Confirmation: By completing your purchase, you acknowledge that you have read, understood, and agreed to all terms above. For any questions, please contact our support team prior to ordering.
