Cylinder Head & Cover Assy

Brand: Mortch Motor
Product Code: MICF0GR0-022000-30000

Product Viewed: 4

Availability: 15

Weight: 3.10kg

0 reviews / Write a review

US$413.17

Shipping To：

More Quotes

Qty

Buy Now

Tell a Friend Ask a Question

CFMoto Cylinder Head & Cover Assy (Complete with Valves, Rocker Arms, etc.)

OEM Part Number 0GR0-022000-20000

Fits CFMoto 500cc / 550cc Multiple Models (191R Engine)

📋 Product Overview

This is a genuine quality cylinder head assembly for CFMoto, including the cylinder head, valves, valve springs, rocker arms, and all related valve train components. Directly replaces OEM part number 0GR0-022000-20000. This assembly is precision assembled and tested to ensure precise fitment and reliable performance. It is the ideal choice for engine overhaul or cylinder head replacement.

✨ OEM Quality: Strictly manufactured according to CFMoto original standards, all components dimensions and materials fully comply with manufacturer requirements, ensuring perfect match and reliable performance.

📦 Included Components

Cylinder Head

Cylinder Head (0JY0-022100): 1 pc

Valve Components

Intake Valve (0800-022004): 2 pcs

Exhaust Valve (0800-022005): 2 pcs

Valve Lock Clip (0800-022016): 8 pcs

Valve Stem Seal (0010-022500): 4 pcs

Spring Components

Valve Spring (0800-022006): 4 pcs

Upper Spring Seat (0800-022007): 4 pcs

Lower Spring Seat (0800-022008): 4 pcs

Rocker Arm Components

Intake Rocker Arm (0800-022500-1000): 1 set

Exhaust Rocker Arm (0800-022600-1000): 1 set

Rocker Arm Shaft (0800-022001): 1 pc

📐 Valve Specifications

Specification	Intake Valve	Exhaust Valve
Length	88.7 mm	90.1 mm
Stem Diameter	5 mm	5 mm
Head Diameter	29 mm	33 mm

🔧 Valve Clearance (Cold Engine)

Intake: 0.06 - 0.14 mm

Exhaust: 0.11 - 0.19 mm

🔧 Compatible Models

CForce 500/520/550 ATV Models:

ATV CF500ATR CForce 520 191R-X550
ATV CF500ATR-2L CForce 520L 191R-X550
ATV CF500ATR-2L(T3a) CForce 520L 191R-X550
ATV CF500ATR-2L(T3b) CForce 520L 191R-X550
ATV CF500ATR-2LC CForce 520L 191R-X550
ATV CF500ATR-2S CForce 520S 191R-X550
ATV CF500ATR-2S(T3a) CForce 520S 191R-X550
ATV CF500ATR-2S(T3b) CForce 520S 191R-X550
ATV CF500ATR-2SC CForce 520S 191R-X550
ATV CF500ATR-3 CForce 520 191R-X550
ATV CF500ATR-3(T3a) CForce 520 191R-X550
ATV CF500ATR-5L(T3b) COBALT MAX T3 191R FOR CF500ATR-5L&5S
ATV CF500ATR-5S(T3b) COBALT T3 191R FOR CF500ATR-5L&5S
ATV CF500ATR-9L CForce 550 191R-E FOR CF500AU-9L/9S
ATV CF500ATR-9L(T3a) CForce 550 191R-E FOR CF500AU-9L/9S
ATV CF500ATR-9L(T3b) CForce 550 191R FOR CF500AU-9L/9S
ATV CF500ATR-9S(T3a) CForce 550 191R-E FOR CF500AU-9L/9S
ATV CF500ATR-9S(T3b) CForce 550 191R FOR CF500AU-9L/9S
ATV CF500ATR-A CForce 550 191R-X550
ATV CF500AU-6B CForce 550 191R-C FOR CF500AU-6B
ATV CF500AU-6L CForce 550 191R-X550
ATV CF500AU-6L(CA) CForce 550HO 191R-X550(CA)
ATV CF500AU-7A CForce 520S 191R FOR CF500AU-7S&7L
ATV CF500AU-7C CForce 520L 191R FOR CF500AU-7S&7L
ATV CF500AU-7L CForce 520L 191R FOR CF500AU-7S&7L
ATV CF500AU-7LF CForce 520L 191R-E
ATV CF500AU-7S CForce 520S 191R FOR CF500AU-7S&7L
ATV CF500AU-7S(AU) CForce 500S 191R FOR CF500AU-7S&7L
ATV CF500AU-7S(CA) CForce 500S 191R FOR CF500AU-7S&7L(CA)
ATV CF500AU-7S(US) CForce 500S 191R FOR CF500AU-7S&7L(US)
ATV CF500AU-7SF CForce 500S/CForce 520S 191R-E
ATV CF500AU-8L COBALT MAX L7e CF500AU-8S/8L
ATV CF500AU-8S COBALT L7e CF500AU-8S/8L
ATV CF500AU-9S CForce 550 191R-E FOR CF500AU-9L/9S
ATV CF500AU-9L CForce 520 L 191R-E FOR CF500AU-9L/9S
ATV CF500AU-10S CForce 550 191R-E
ATV CF500AZ-9S CForce 500/CForce 520 191R FOR CF500AU-9L/9S
ATV CF500AZ-10S CForce 500/CForce 520 191R FOR CF500AU-9L/9S

📌 Compatibility Note: This cylinder head assembly fits the CFMoto 500cc and 550cc models listed above, equipped with 191R series engines (including 191R-X550, 191R-C, 191R-E, etc.). Please verify your engine model to ensure correct fitment.

⚙️ Features

Direct OEM Replacement: Exactly matches CFMoto part number 0GR0-022000-20000.
Complete Assembly: Includes cylinder head, valves, valve springs, rocker arms, and all valve train components - everything in one package.
Precision Machining: Cylinder head made of high-quality aluminum alloy casting, precision machined for optimal sealing and heat dissipation.
High-Temperature Alloy Material: Valves made of high-quality heat-resistant alloy steel, ensuring stable operation under high temperature and pressure.
Pre-Assembled: Valves and rocker arms are pre-assembled, reducing installation time and difficulty.

✅ Service Tip: The cylinder head assembly is typically replaced during engine overhaul, when the cylinder head is damaged (cracked, warped), or when valve seats are severely worn. When installing a new cylinder head, always use a new head gasket and tighten the cylinder head bolts to the specified torque and sequence. Valve clearance must be adjusted after installation.

⚠️ Installation Note: Thoroughly clean the cylinder block mating surface before installation, ensuring no old gasket residue remains. Install a new head gasket and position the cylinder head assembly. Tighten the cylinder head bolts in the sequence and torque steps specified in your service manual. After installing the timing system, rotate the crankshaft to check for interference. Start the engine and check for abnormal noise and leaks, then adjust valve clearance.

🔧 Compatibility Notice

Please verify that this part fits your specific vehicle model and year. Many vehicles share similar names but use different components depending on year or market region.
We strongly recommend cross-checking with your vehicle's owner's manual or contacting us for confirmation before placing your order.

📄 Product Disclaimer

Product images, measurements, and descriptions are for reference only. Slight variations in color or appearance may occur due to manufacturing batches or photography lighting—functional specifications remain identical to the ordered part.
Professional installation is mandatory. Mortch Motor assumes no liability for damages, injuries, or losses resulting from improper installation, misuse, unauthorized modification, or abnormal operation.
