Crankshaft Speedometer Sensor

Brand: Mortch Motor
Product Code: MICF0GQV-011020-3100

Product Viewed: 9

Availability: In Stock

Weight: 0.05kg

0 reviews / Write a review

US$15.95

Shipping To：

More Quotes

CFMoto Speedometer Sensor (Vehicle Speed Sensor)

OEM Part Number 0GQV-011020-3100

Fits CFMoto 400cc / 600cc / 800cc Multiple Models (191Q-H / 191S / 2V91W Engines)

📋 Product Overview

This is a genuine quality speedometer sensor (vehicle speed sensor) for CFMoto, directly replacing OEM part number 0GQV-011020-3100. This sensor is used to detect the rotating speed of the engine output shaft and provide the signal for the ECU to determine the vehicle speed. It is a Hall effect sensor that varies its output voltage in response to a magnetic field.

✨ Operating Principle: Hall effect sensors generate pulse signals by sensing changes in the magnetic field from magnets or gears on rotating components. The ECU calculates rotational speed and vehicle speed based on pulse frequency. Advantages include fast response, long service life, and strong anti-interference capability.

📐 Specifications

Part Number: 0GQV-011020-3100

Type: Hall Effect Sensor

Function: Detects engine output shaft speed for vehicle speed calculation

🔧 Compatible Models & Engines

🏍️ 400cc Series — 191Q-H Engine

CF400ATR-3L CForce 450L Series (including T3a/T3b variants)
CF400ATR-3S CForce 450 Series (including T3a/T3b variants)
CF400AZ-3L CForce 400 TOURING / CForce 450L Series
CF400AZ-3S CForce 400 / CForce 450 Series
Includes various region versions (AU/CA/RU/ST/US) and government/fire department versions

🏍️ 600/625cc Series — 191S / 191S-A / 191S-B / 191S-U6 Engines

CF600ATR-2LC CForce 625 Touring Series (191S-B)
CF600ATR-2SC CForce 625 Series (191S-B)
CF600AU-3LA CForce 600/625 Touring Series (191S-B)
CF600AU-3LF CForce 600/625 Touring Series (191S-A)
CF600AU-3LH CForce 600/625 Touring Series (191S-A)
CF600AU-3SA CForce 625 EPS Series (191S-B)
CF600AU-3SF CForce 600 Series (191S-A)
CF600AZ-3LA CForce 600 Touring Series (191S-B)
CF600AZ-3S / 3SA CForce 600 Series (191S-B)
CF600UTR / CF600UU / CF600UZ UForce 600 Series (191S-U6)

🏍️ 800cc Series — 2V91W-K Engine

UTV CF800UTR-4 UForce 800 XL (2V91W-K)

📌 Compatibility Note: This speed sensor fits the engine series listed above, mainly covering CFMoto 400cc (191Q-H), 600cc (191S series) and some 800cc (2V91W-K) models. Due to the large number of variants, this list summarizes the main compatible models. Please verify your original part number is 0GQV-011020-3100 to ensure correct fitment.

⚙️ Features

Direct OEM Replacement: Exactly matches CFMoto part number 0GQV-011020-3100.
Hall Effect Technology: Non-contact detection using Hall effect principle, fast response, long service life.
Precise Signal Output: Provides accurate vehicle speed signal to ECU, ensuring correct speedometer display and engine control system operation.
Weather Resistance: Sealed design, oil-proof, water-resistant, and vibration-resistant for harsh operating environments.
Plug and Play: Direct replacement for faulty original sensor, no additional modifications required.

⚠️ Common Failure Symptoms:

Speedometer not working or displaying incorrectly
Cruise control inoperative (if equipped)
Engine warning light illuminated with speed sensor related fault codes
Rough shifting (some models use speed signal for shift assistance)

✅ Service Tip: When the speed sensor fails, it typically requires replacement. Before installation, check the sensor mounting hole for metal debris or contamination, and clean the sensor sensing face. Do not overtighten during installation to avoid damaging the sensor housing. After installation, start the engine and test drive to verify speedometer function.

⚠️ Installation Note: Disconnect the battery negative terminal before installation. Remove the old sensor and clean the mounting hole. Apply a small amount of oil to the new sensor O-ring, then insert into the mounting hole and tighten the mounting bolt to the torque specified in your service manual. Connect the electrical connector, ensuring it locks securely. Reconnect the battery and test sensor function.

🔧 Compatibility Notice

Please verify that this part fits your specific vehicle model and year. Many vehicles share similar names but use different components depending on year or market region.
We strongly recommend cross-checking with your vehicle's owner's manual or contacting us for confirmation before placing your order.
