Reservoir Tank Assy

Brand: Mortch Motor
Product Code: MICF9DQV-180300-3000

Product Viewed: 1

Availability: Pre-Order🔔

Weight: 0.18kg

0 reviews / Write a review

US$13.60

Shipping To：

More Quotes

Qty

Pre-Order

Tell a Friend Ask a Question

🔧 CFMoto Reservoir Tank Assembly

📦 Part Number: 9DQV-180300-3000

💧 Coolant Expansion Tank · OEM Specification

📍 Installation Position: Engine Bay Cooling System

✅ OEM Quality · Heat Resistant · Fits CFMoto CForce 1000/850/450/500 & GOES TERROX Series

📋 Product Overview

This product is a CFMoto OEM-spec reservoir tank assembly (coolant expansion tank), part number 9DQV-180300-3000. The reservoir tank is an important component of the engine cooling system, storing coolant that expands and overflows from the radiator, and drawing it back into the radiator when the engine cools, maintaining stable cooling system pressure. Manufactured from high-quality heat-resistant plastic with excellent sealing and durability.

Over time, the reservoir tank may become aged, cracked, leaky, or internally blocked, leading to coolant loss and engine overheating. Timely replacement of a damaged reservoir tank assembly is essential to ensure proper engine cooling system operation.

✅ Genuine Quality Assurance: Manufactured strictly to CFMoto original technical standards. Dimensions and hose connection positions are identical to the original part for a perfect replacement.

📐 Specifications

🔖 Part Number: 9DQV-180300-3000

🏷️ Product Type: Reservoir Tank Assembly / Coolant Expansion Tank

📍 Installation Position: Engine Bay Cooling System

🧪 Material: Heat-Resistant Engineering Plastic

🔧 Function: Coolant Storage · Pressure Equalization

🚗 Compatible Models (CFMoto CForce / GOES TERROX Series)

This reservoir tank assembly (9DQV-180300-3000) fits the following CFMoto models:

🏍️ CForce 1000 Series

CF1000ATR-2 · 2024-2026 · CForce 1000 X10
CF1000ATR-2A · 2025-2026 · CForce 1000 X10 Overland
CF1000AU-2 · 2025-2026 · CForce 1000 X10 Overland

🏍️ GOES TERROX Series

CF1000ATR-4L · 2026 · GOES TERROX 1000 T3b
CF1000AU-4L · 2026 · GOES TERROX 1000 EPS

🏍️ CForce 400/450 Series

CF400ATR-3L(T3b) · 2022-2026 · CForce 450 L
CF400ATR-3S(T3b) · 2022-2023 · CForce 450
CF400AU-3L · 2022-2025 · CForce 450L
CF400AU-3LH · 2025-2026 · CForce 450L
CF400AU-3S · 2022-2023 · CForce 450S
CF400AZ-3L · 2025 · CForce 400 Touring / CForce 450 L

🏍️ CForce 500/520 Series

CF500ATR-9L(T3a/T3b) · 2022-2026 · CForce 520 L
CF500ATR-9S(T3b) · 2022-2023 · CForce 550
CF500AU-9L · 2022-2025 · CForce 520 L
CF500AU-9LH · 2025-2026 · CForce X5 520L
CF500AU-9S · 2022-2024 · CForce 520 / CForce 500

🏍️ CForce 800/850 Series

CF800ATR-5 · 2024-2026 · CForce 850 X8 Touring
CF800AU-3 · 2025-2026 · CForce 850 X8 Touring

📌 Fitment Note: This reservoir tank assembly fits the CFMoto CForce 1000, CForce 800/850, CForce 400/450, CForce 500/520, and GOES TERROX series ATV models listed above. Year ranges are merged for display — all model years within each range are applicable. If your specific model is not listed, please contact customer service with your VIN for confirmation.

⚙️ Product Features

✅ OEM Specification: Manufactured strictly to CFMoto original technical standards; dimensions are identical to the original part.
🛡️ Heat-Resistant Material: Made from high-quality heat-resistant engineering plastic with excellent aging resistance.
💪 Reliable Sealing: Tank cap and hose connections provide good sealing to prevent coolant leaks.
🔧 Direct Replacement: Directly replaces aged, cracked, or leaking original reservoir tanks.
🌡️ Protects Cooling System: Ensures proper coolant circulation and prevents engine overheating.

✅ Signs Your Reservoir Tank Needs Replacement:
• Tank body has cracks, aging, or deformation.
• Coolant leakage visible at tank connections.
• Coolant level drops abnormally.
• Engine frequently overheats.
• Tank is internally blocked, preventing proper coolant circulation.
If any of these symptoms occur, replace the reservoir tank assembly promptly.

✅ Installation Tips:
1. Ensure the engine is completely cool before installation.
2. When removing the old tank, have a container ready to catch residual coolant.
3. Clean the mounting area and inspect connecting hoses for damage.
4. Install the new reservoir tank and connect the inlet and return hoses.
5. Fill with the appropriate coolant to the specified level.
6. Start the engine, check for leaks, and recheck the coolant level after cooling.
Professional installation is recommended.

⚠️ Important Notice: This product is a CFMoto reservoir tank assembly, part number 9DQV-180300-3000. Fits the CFMoto CForce 1000, CForce 800/850, CForce 400/450, CForce 500/520, and GOES TERROX series ATV models listed above. Minor differences may exist between production batches. If your specific model is not listed, please contact customer service with your VIN for compatibility confirmation. Images are for reference only; actual product may vary.

🔧 Compatibility Notice

Please verify that this part fits your specific vehicle model and year. Many vehicles share similar names but use different components depending on year or market region.
We strongly recommend cross-checking with your vehicle's owner's manual or contacting us for confirmation before placing your order.

📄 Product Disclaimer

Product images, measurements, and descriptions are for reference only. Slight variations in color or appearance may occur due to manufacturing batches or photography lighting—functional specifications remain identical to the ordered part.
Professional installation is mandatory. Mortch Motor assumes no liability for damages, injuries, or losses resulting from improper installation, misuse, unauthorized modification, or abnormal operation.

💰 Import Duties & Taxes

All listed prices EXCLUDE shipping costs, import duties, taxes, and customs clearance fees. These charges (if applicable) are determined and collected by your local customs authority and are solely the buyer's responsibility.
In case of return due to unpaid duties/taxes or refusal to clear customs, the buyer shall bear the original shipping cost, return shipping fees, and any associated administrative charges deducted from the refund.

📌 Order Confirmation: By completing your purchase, you acknowledge that you have read, understood, and agreed to all terms above. For any questions, please contact our support team prior to ordering.
