Block Assy.

Brand: Mortch Motor
Product Code: MICFQ890-310010

Product Viewed: 2

Availability: 1

Weight: 0.03kg

0 reviews / Write a review

US$16.60

Shipping To：

More Quotes

Qty

Buy Now

Tell a Friend Ask a Question

🔧 CFMoto Block Assembly (Front/Rear Axle)

📦 Part Number: Q890-310010

⚙️ Block Assy · Shift Block Assembly · OEM Spec

📍 Installation Location: Transmission/Transfer case / Inside shift actuator mechanism

✅ Single unit · Precision alloy steel · Direct fit · Compatible with multiple CFMoto ATV/SSV/UTV models

📋 Product Overview

This is a CFMoto OEM-spec Block Assembly (front/rear axle), part number Q890-310010, sold as a single unit. This block assembly is a core component of the transmission or transfer case shift actuator mechanism, consisting of the shift block body and related mating parts. Installed inside the shift mechanism, it drives the shift fork to engage gears, controlling power distribution to the front and rear axles and drive mode selection — a critical assembly for ensuring smooth shifting and drivetrain reliability.

Over time, the original block assembly may suffer from working surface wear, increased clearance, or deformation under high-load and frequent shifting conditions — leading to inaccurate shifting, gear jumping, or poor shift feel. Replacing with an OEM-spec block assembly is an essential repair to restore transmission/transfer case shifting precision and reliability.

✅ OEM Quality Assurance: Manufactured strictly to CFMoto original technical standards. Made from precision alloy steel, with dimensions, hardness, and wear resistance identical to the genuine part, ensuring a perfect replacement and reliable shifting performance.

📐 Specifications

🔖 Part Number: Q890-310010

🏷️ Product Name: Block Assembly (Front/Rear Axle)

📦 Packaging: Single unit

📍 Installation: Transmission/Transfer case / Shift actuator mechanism

🧪 Material: Precision alloy steel

⚙️ Function: Drive shift fork · Shift actuation · Drive mode control

🚗 Vehicle Compatibility

This Block Assembly (part number Q890-310010, single unit) fits the following CFMoto models:

🏍️ ATV Series

CF1000ATR · CForce 1000
CF1000ATR-2 · CForce 1000 X10
CF1000ATR-2A · CForce 1000 X10 Overland
CF1000ATR-3 · CForce 1000 MUD
CF1000ATR-3L · CForce 1000 MV
CF1000ATR-4L · GOES TERROX 1000 T3b
CF1000AU · CForce 1000 EPS Overland
CF1000AU-2 · CForce 1000 X10 Overland
CF1000AU-4L · GOES TERROX 1000 EPS
CF1000AU-F · CForce 1000 Overland
CF400ATR-3L(T3b) · CForce 450 L
CF400ATR-3S(T3b) · CForce 450S
CF400ATR-7L · CForce C4 Touring T3b
CF400AU-3L · CForce 450L
CF400AU-3LH · CForce 450L
CF400AU-3S · CForce 450S
CF400AZ-3L · CForce 400 Touring/CForce 450 L
CF500ATR-15L · GOES TERROX 550L T3b
CF500ATR-17L · GOES TERROX 500L EPS T3b
CF500ATR-9L(T3a) · CForce 520 L
CF500ATR-9L(T3b) · CForce 520 L
CF500ATR-9S(T3b) · CForce 520S
CF500AU-9L · CForce 520 L
CF500AU-9LH · CForce X5 520L
CF500AU-9S · CForce 520S/CForce 500S
CF600ATR-2L(T3b) · CForce 625 Touring
CF600ATR-2LC · CForce 625 Touring
CF600ATR-2S(T3b) · CForce 625
CF600ATR-2SC · CForce 625
CF600AU-3L · CForce 600 Touring/625 Touring
CF600AU-3LF · CForce 600 Touring/625 Touring
CF600AU-3LH · CForce 600 Touring/625 Touring
CF600AU-3S · CForce 600/625
CF600AU-3SF · CForce 625S EPS Touring
CF800ATR-3 · CForce 850XC
CF800ATR-5 · CForce 850 X8 Touring
CF800AU-2A · CForce 850XC
CF800AU-2AF · CForce 800XC/CForce 850XC
CF800AU-3 · CForce 850 X8 Touring

🏎️ SSV Series

CF1000STR(T1b) · Z10 Turbo
CF1000STR-3L · ZForce 950 Sport-4
CF1000STR-L · Z10-4 Turbo
CF1000SZ · Z10
CF1000SZ-L · Z10-4
CF1000UTR-6(T1b) · ZForce 950 Sport
CF1000UTR-C · ZForce 1000 Sport
CF800SU-3 · ZForce 800 Sport

🚜 UTV Series

CF1000UTR-3 · UForce 1000
CF1000UTR-5 · UForce 1000 XL
CF1000UTR-8 · UForce U10 PRO(T1b)
CF1000UTR-8K · UForce U10 PRO Highland
CF1000UTR-8L · UForce U10 XL PRO
CF1000UU · UForce 1000
CF1000UU-2 · UForce 1000 XL
CF200DUTR(EU167) · (unnamed)
CF200DUU · U6 EV
CF600UTR · UForce 600
CF600UTR(T1b) · UForce 600
CF800UTR-4 · UForce 800 XL

📌 Fitment Note: This block assembly fits the transmission or transfer case shift actuator mechanism of the listed CFMoto models. Sold as a single unit. If your specific model is not listed, please contact us with your VIN to confirm compatibility.

⚙️ Product Features

✅ OEM Original Spec: Manufactured to CFMoto original technical standards; dimensions, hardness, and wear resistance match the genuine part exactly.
🛡️ Precision Alloy Steel: Made from premium alloy steel with precision machining and heat treatment for excellent wear resistance and impact strength.
🔧 Direct Fitment: Direct replacement for the original part — no modifications required.
💪 Precise Shifting: Precision-machined working surfaces ensure accurate engagement with the shift fork for reliable gear selection.
🔄 Direct Replacement: Replaces worn, deformed, or damaged original block assemblies.

✅ Typical signs you need to replace the Block Assembly:
• Inaccurate shifting — vague gear engagement or some gears cannot be selected.
• Gear jumping or popping out of gear while driving.
• Abnormal noise from the transmission/transfer case (metal grinding or knocking).
• Working surfaces show heavy wear or deformation during transmission disassembly.
• Excessive play or binding feel during shift operation.
If any of these occur, inspect and replace the block assembly promptly to restore normal transmission/transfer case shifting performance.

✅ Installation Tips:
1. Confirm the assembly is the correct Q890-310010 matching the original.
2. Remove the transmission or transfer case (raise the vehicle with proper support).
3. Disassemble to access the shift actuator mechanism and remove the old block assembly.
4. Inspect the shaft and mating surfaces for wear or damage.
5. Install the new block assembly in the correct orientation, ensuring proper engagement with the shift fork.
6. Check that the block slides smoothly on the shaft with no binding.
7. Reassemble the transmission/transfer case per the service manual and fill with the specified lubricant.
8. Test shift operation after installation to ensure smooth engagement in all gears.
Installation involves transmission/transfer case disassembly — requires special tools and expertise. Professional installation is strongly recommended.

⚠️ Important Note: This product is a CFMoto Block Assembly, part number Q890-310010, sold as a single unit. Fits the listed CFMoto models. Slight variations may occur between production batches. If your specific model is not listed, please contact us with your VIN to confirm compatibility. Images are for reference only; actual product may vary. Transmission repairs involve precision assembly — always follow the service manual specifications and torque requirements during installation.
