C4/C5 Cylinder Gasket

🔧 CFMoto Cylinder Gasket Set

📦 Included Parts: Cylinder Head Gasket · Cylinder Body Gasket

⚙️ Cylinder Gasket Set · Engine Seal Gasket · OEM Spec

📍 Installation: Between cylinder head & cylinder · Between cylinder & crankcase

✅ Complete set with 2 parts · OEM specification · Fits CFMoto CForce C4/C5 & GOES TERROX models

This is a CFMoto OEM-spec cylinder gasket set, including cylinder head gasket (1 pc) and cylinder body gasket (1 pc) — 2 pieces in total. This gasket set is a critical component of the engine sealing system, installed between the cylinder head and cylinder, and between the cylinder and crankcase, to seal the combustion chamber, oil galleries, and coolant passages — preventing gas, oil, and coolant leaks.

Cylinder gaskets are subjected to high temperatures, high pressures, and thermal cycling. They may fail due to aging, fatigue, or damage — resulting in power loss, oil emulsification, coolant consumption, or white exhaust smoke. Replacing with an OEM-spec gasket set ensures the engine regains reliable sealing and extends its service life.

• ✅ OEM Specification: Manufactured to CFMoto's original technical standards. Material, dimensions, and thickness are identical to genuine parts.
• 🛡️ Complete Set: Includes both cylinder head gasket and cylinder body gasket — all essential parts in one package.
• 🔧 Premium Sealing Material: Made from high-temperature, oil-resistant, coolant-resistant sealing material for long-term reliability.
• 💪 Reliable Sealing: Effectively seals combustion chamber, oil, and coolant passages — preventing leaks.
• 🔄 Direct Replacement: Can be used to directly replace aged, damaged, or failed original cylinder gaskets.

✅ Typical signs that the cylinder gasket set needs replacement:
• Loss of engine power, poor acceleration.
• Abnormal coolant consumption — radiator level keeps dropping.
• Oil emulsification (milky white foam in oil).
• White smoke from exhaust (coolant entering combustion chamber).
• Engine overheating with abnormal temperature rise.
• Visible oil stains or coolant seepage at cylinder/head joint.
If any of these signs appear, please inspect and replace the cylinder gasket set promptly.

✅ Installation Tips:
1. Remove the cylinder head and cylinder, clean off old gasket residue.
2. Clean sealing surfaces — ensure they are free of oil, debris, and scratches.
3. Inspect cylinder head and cylinder flatness; resurface if necessary.
4. Install the new cylinder body gasket (between cylinder and crankcase).
5. Install the new cylinder head gasket (between cylinder head and cylinder).
6. Torque cylinder head bolts to specification in the correct sequence.
7. Refill coolant and oil, start the engine, and check for leaks.
Professional installation is recommended. Always follow factory torque specifications and tightening sequence.

⚠️ Important Notice: This product is a CFMoto cylinder gasket set, including cylinder head gasket (1 pc) and cylinder body gasket (1 pc) — 2 pieces total. Fits CFMoto CForce C4/C5 series and GOES TERROX models equipped with 192Q or 192R engines. Minor variations may exist between production batches. If your specific model is not listed, please contact us with your VIN to confirm compatibility. Images are for reference only; actual product may differ slightly.
